Каталог запасных частей к технике: Zoomlion ZT68J. Label assembly 00771107000000000
2
2
3
6
7
11
11
12
14
14
14
14
15
16
17
18
20
20
20
20
24
26
26
26
26
26
27
27
28
29
30
33
35
37
37
38
38
41
41
42
43
47
48
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2 | 00773407000201070 | Electrocution hazard | |
| 3 | 00773407000201080 | Ground control box instruction | |
| 6 | 00773407000201160 | Trained and authorized personnel only | |
| 7 | 00773407000201170 | No touch | |
| 11 | 00773407000201210 | Extrusion hazard | |
| 12 | 00773407000201220 | ZT20J plate | |
| 14 | 00773407000201240 | No lifting | |
| 15 | 00773407000201250 | Stop pins must be inserted during transportation | |
| 16 | 00773407000201260 | Precautions for use | |
| 17 | 00773407000201270 | Prohibition of high-pressure water flushing | |
| 18 | 00773407000201310 | Never change the limit switch | |
| 20 | 00773407000201360 | Tilt hazard and tire | |
| 24 | 00773407000201400 | Read instruction carefully | |
| 26 | 00773407000201420 | Tie down | |
| 27 | 00773407000201430 | Lifting | |
| 28 | 00773407000201440 | Main power switch operating instruction | |
| 29 | 00773407000201450 | Inspection before operation | |
| 30 | 00773407000201470 | Burn preventing | |
| 33 | 00771107000201020 | Overturning hazard | |
| 35 | 00771107000201010 | Range of motion diagram | |
| 37 | 00771407000201080 | Blue arrow | |
| 38 | 00771407000201090 | Yellow arrow | |
| 41 | 00773407000201030 | Covering parts LOGO2 | |
| 42 | 00771407000201130 | Boom LOGO | |
| 43 | 00771107000201040 | Model No. | |
| 47 | 00771407000201170 | Environmental information label | |
| 48 | 00771107000201030 | Transport and lifting instruction |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
