Каталог запасных частей к технике: Zoomlion ZLJ5500V3. VARIABLE PUMP A4VG125EP4X-NAF02K023EP D1010000709_32793Y

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
Позиция на иллюстрации Заводской номер детали Название детали
1010000709 1010000709 variable pump
1 1040301963 Circlipretaining ring
2 1019803832 Shaft seal cover
3 1089800072 Oil seal
4 1081000548 O-ring 97.5x3.55
5 1019803833 Drive shaft
6 1019803820 Cylindrical roller bearing
7 1040301274 Circlip for shaft
8 1019802851 Name plate
9 1040400045 Rivet
10 1019803842 Threaded rod
11 1019803821 Nut
12 1040501264 Elastic cylindrical pin
13 1019803819 Cylindrical roller bearing
14 1019803835 Cradle
15 1019803837 Ejector rob
16 1019803851 Piston
17 1019803839 Return spring
18 1019803841 Guide sleeve
19 1019803843 Pin
20 1040501265 Cylindrical pin
21 1019803849 Plate
22 1040102112 Allen screw
23 1089800070 O ring
24 1019803831 Rear cover
25 1081001494 O ring
26 1089800071 Rubber flat washer
27 1019803852 Constant pressure and load sensitive control valve
28 1019803830 Housing
29 1089800066 O ring
30 1019803829 Plug
31 1019803824 Pin
32 1089800032 O ring
33 1019803853 Plug
34 1040102113 Allen screw
35 1019803846 Piston shoe assy
36 1019803847 Return disk
37 1019803848 Ball hinge
38 1019803827 Adjusting shim
39 1019803828 Disc spring
40 1019803845 Cylinder
41 1019803844 Valve plate
42 1019803838 Ejector rob
43 1019803836 Piston
44 1019803840 Spring
45 1019803818 Cylindrical roller bearing
46 1019803826 Damping plug
47 1040501267 Cylindrical pin
48 1019803850 Connecting set
49 1089800067 O ring
50 1019803834 Transition plate
51 1040102114 Allen screw
52 1019803854 Double-headed plug
53 1089800069 O ring
54 Plug Plug
55 1019803825 Damping plug
56 1089800029 O ring
57 Plug Plug
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
