Каталог запасных частей к технике: Zoomlion ZLJ5500V3. ELECTRICAL SYSTEM, CHASSIS FRAME D00672306300000000Y

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
4
5
6
6
6
6
6
6
7
8
9
9
9
9
9
10
11
12
13
14
15
16
17
18
19
21
22
23
24
25
26
27
28
30
31
32
33
34
35
36
37
38
39
40
41
51
52
Позиция на иллюстрации Заводской номер детали Название детали
00672306300000000 00672306300000000 Electrical system, chassis frame
1 1020400094 Basin electric horn
2 1040000288 Bolt
3 1040300063 Washer
4 00672306300200004 Cable harness in chassis frame
5 00672306300400003 Ecu cable bundle 6
6 1040300066 Washer
7 1020700443 Wire holder
8 1020700444 Wire harness claspbracket
9 1040200192 Nut
10 00672306301200000 Wire
11 00671556311800000 Battery negative pole ground wire
12 00671556311200000 Connecting wire from battery to battery relay
13 00671556301600000 Battery series wire
14 1040000018 Bolt
15 1040000075 Bolt
16 1040300051 Washer
17 1040300062 Washer
18 1040200111 Nut
19 1020900023 Battery bracket assy
21 1020500657 Support control unit assy
22 1040100047 Screw
23 1040300045 Washer
24 1040300044 Washer
25 1040200100 Nut
26 1020400093 Buzzer
27 00672306300800001 Platform cable bundle
28 1020400053 Sliding beam illumination
30 00672306301000001 Platform cable bundle
31 1021400016 Fuel sensor
32 1020500656 Support control unit assy
33 1020400335 Side marking light
34 1021400257 Odometer sensor concave type
35 00671556302000000 Ground wire
36 1040000110 Bolt
37 1020900039 Power control box
38 00672306300600002 Cable harness in engine
39 1020500009 Warning lamp switch
40 1020500046 Brake lamp switch
41 1031700064 Electronic accelerator pedal assembly
49 1990200005 Nylon strap
50 1990200008 Nylon strap
51 1020400413 7-function rear combination signals, left
52 1020400415 7-function rear combination signals, right
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
