Каталог запасных частей к технике: Zoomlion ZE205E. Multi Control Valve
101
102
103
104
154
155
164
165
165
165
165
165
165
165
165
165
165
166
166
166
166
166
166
166
166
167
167
167
167
168
168
168
168
251
252
252
324
325
338
391
601
974
974
975
976
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 101 | 1019801431 | Casing A | |
| 102 | 1019801430 | Casing B | |
| 103 | 1019801106 | Straight-Travelvalve | |
| 103 | 1019801104 | Straight-Travelvalve | |
| 104 | 1019801107 | Boom Priority Valve | |
| 153 | 1019801306 | Roh Plug | |
| 154 | 1019801307 | Roh Plug | |
| 155 | 1019801305 | Roh Plug | |
| 158 | 1019801339 | Plug | |
| 159 | 1019801451 | Plug | |
| 164 | 1019801288 | O-Ring | |
| 165 | 1019801277 | O-Ring | |
| 166 | 1019801283 | O-Ring | |
| 167 | 1019801291 | O-Ring | |
| 168 | 1019801294 | O-Ring | |
| 169 | 1019801278 | O-Ring | |
| 201 | 1019801445 | Cover.Spring | |
| 202 | 1019801458 | Cover.Spring | |
| 203 | 1019801447 | Cover.Spring | |
| 204 | 1019801426 | Cover.Spring | |
| 206 | 1019801446 | Cover.Arm | |
| 209 | 1019801419 | Flange | |
| 251 | 1019801380 | Logiccontrol Valve | |
| 252 | 1019801385 | Assy.Lock Valve | |
| 254 | 1019801389 | Swing Logic Valve | |
| 261 | 1019801455 | O-Ring | |
| 262 | 1019801454 | O-Ring | |
| 264 | 1019801280 | O-Ring | |
| 273 | 1019801318 | Screw.Hex.S.H.C | |
| 301 | 1019801400 | Spool.Travel | |
| 302 | 1019801109 | Assy.Arm Spool | |
| 303 | 1019801102 | Spool.Boom | |
| 304 | 1019801101 | Spool.Blcket | |
| 305 | 1019801396 | Spool.Swing | |
| 306 | 1019801110 | Spool.Arm | |
| 307 | 1019801395 | Spool.Boom | |
| 309 | 1019801399 | Spool Option | |
| 310 | 1019801401 | Spool Travel | |
| 324 | 1019801402 | Spring | |
| 325 | 1019801411 | Spring | |
| 326 | 1019801410 | Spring | |
| 327 | 1019801464 | Spring | |
| 328 | 1019801465 | Spring | |
| 329 | 1019801459 | Spring | |
| 331 | 1019801457 | Seat.Spring | |
| 332 | 1019801462 | Seat.Spring | |
| 333 | 1019801463 | Bolt.Spacer | |
| 334 | 1019801449 | Stopper | |
| 335 | 1019801450 | Stopper | |
| 336 | 1019801461 | Bolt.Spacer | |
| 337 | 1019801443 | Stopper | |
| 338 | 1019801434 | Stopper | |
| 339 | 1019801435 | Stopper | |
| 355 | 1019801437 | Piston | |
| 356 | 1019801453 | Piston | |
| 370 | 1019801452 | Spring | |
| 371 | 1019801460 | Spring | |
| 372 | 1019801412 | Spring | |
| 373 | 1019801413 | Spring | |
| 375 | 1019801425 | Spring | |
| 391 | 1019801398 | Straight Travel Spool | |
| 392 | 1019801421 | Spool Bypath-Cut | |
| 511 | 1019801423 | Poppet | |
| 513 | 1019801420 | Poppet | |
| 515 | 1019801422 | Poppet | |
| 516 | 1019801448 | Poppet | |
| 521 | 1019801403 | Spring | |
| 522 | 1019801404 | Spring | |
| 523 | 1019801308 | Spring | |
| 551 | 1019801395 | Spool.Boom | |
| 552 | 1019801417 | Plug | |
| 554 | 1019801416 | Plug | |
| 555 | 1019801387 | Assy Check Valve | |
| 561 | 1019801296 | O-Ring | |
| 601 | 1019801105 | Assy Main Rettef | |
| 602 | 1019800143 | Assy Port Rellet | |
| 603 | 1019801379 | Assy Port Rellet | |
| 611 | 1019801388 | Assy Nege-Con Rellet | |
| 971 | 1019801311 | Screw.Hex.S.H.C | |
| 974 | 1019801312 | Screw.Hex.S.H.C | |
| 975 | 1019801103 | Screw.Hex.S.H.C | |
| 976 | 1019801313 | Screw.Hex.S.H.C | |
| 977 | 1019801357 | Plate Name | |
| 978 | 1019801321 | Pin |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
