Каталог запасных частей к технике: Zoomlion ZCC1100H. WIRE HARNESS OF JUNCTION BOX (3) D00663116300230001Y

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
12
12
13
14
15
16
Позиция на иллюстрации Заводской номер детали Название детали
00663116300230001 00663116300230001 Wire harness of junction box
1 1020809336 Junction box
2 1020700307 Connector
3 1029901316 Protecting jacket of heavy-duty connector
4 1029901193 Cable joint
5 1029901507 Wiring terminal
6 1029901498 Retaining plate
7 1029901457 Fixer
8 1020805351 Mark bar
9 1020809446 Guide rail
10 1029902138 Pipe-shaped pre-insulating terminal
11 1029902141 Pipe-shaped pre-insulating terminal
12 1029900210 Water-proof cable joint
13 1022396130 Cable joint
14 1029900212 Water-proof cable joint
15 1020700306 Connector
16 1029901307 Protecting jacket of heavy-duty connector
17 1020702673 Connector of solenoid valve
18 1020702675 Connector of solenoid valve
19 1020702674 Connector of solenoid valve
20 1022305375 Flexible control cable
21 1022305371 Flexible control cable
22 1040100617 Screw
23 1020700978 Numbered pipe
24 1020700981 Numbered pipe
25 1029902994 Strap
26 1022200646 Socket
27 1020700951 2-pin plug protecting jacket
28 1020700970 Socket
29 00663116300231011 Indicating plate of junction box
30 1020701025 Sensor cable
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
