Каталог запасных частей к технике: Zoomlion ZCC1100H. WIRE HARNESS OF JUNCTION BOX (1) D00663116300210001Y

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
5
11
11
16
16
17
17
18
19
Позиция на иллюстрации Заводской номер детали Название детали
00663116300210001 00663116300210001 Wire harness of junction box
1 1020809336 Junction box
2 1029901307 Protecting jacket of heavy-duty connector
3 1020700306 Connector
4 1020805351 Mark bar
5 1029901507 Wiring terminal
6 1029901498 Retaining plate
7 1029901457 Fixer
8 1020809446 Guide rail
9 1029902138 Pipe-shaped pre-insulating terminal
10 1029902141 Pipe-shaped pre-insulating terminal
11 1029900210 Water-proof cable joint
12 1020702675 Connector of solenoid valve
13 1020702674 Connector of solenoid valve
14 1020702673 Connector of solenoid valve
15 1020500589 Connector for proximity switch
16 1029900211 Water-proof cable joint
17 1029900220 Metal ring
18 1020700273 Socket cover
19 1020700271 Socket
20 1022305371 Flexible control cable
21 1022305368 Flexible control cable
22 1022305373 Flexible control cable
23 1020700978 Numbered pipe
24 1020700981 Numbered pipe
25 1029902994 Strap
26 1040100617 Screw
27 1020501007 Button
28 1020509003 Push-key film
29 1020806275 Fixing bracket
30 1020509016 Normally closed contact
31 1020701306 Button box
32 00663116300211011 Indicating plate of junction box
33 1020701025 Sensor cable
34 1029902662 Elbow connector
35 1029901635 U-shaped bare terminal
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
