Каталог запасных частей к технике: Zoomlion ZCC1100H. WINCH REDUCER D1030201281_100014Y

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16
16
17
18
19
20
21
22
22
23
24
25
26
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
70
71
72
Позиция на иллюстрации Заводской номер детали Название детали
1030201281 1030201281 Winch reducer
1 Bolt Bolt
2 Lubricatecap Lubricate cap
3 RightDustcap Right Dust cap
4 Bearingseat Bearing seat
5 Bearing Bearing
6 Oilsealring Oil seal ring
7 Feltcircle Felt circle
8 Elasticring Elastic ring
9 Bolt Bolt
10 Supportingaxle Supporting axle
11 Reel Reel
12 Bolt Bolt
13 Endcover End cover
14 Cushion Cushion
15 First-levelsungear First-level sun gear
16 Ocircle O circle
17 First-leveltoothring First-level tooth ring
18 Elasticring Elastic ring
19 Bigtoothring Big tooth ring
20 Stoppingnut Stopping nut
21 Bolt Bolt
22 Bearingseat Bearing seat
23 Stoppingnut Stopping nut
24 Bearingseat Bearing seat
25 Bolt Bolt
26 Floatsthesealingring Floats the sealing ring
27 Elasticring Elastic ring
28 Backplate Back plate
29 Altar Altar
30 Threadplug Thread plug
31 Elasticring Elastic ring
32 Elasticring Elastic ring
33 Backplate Back plate
34 1039804776 External friction lining
35 1009803831 Internal friction piece
36 Splintedtube Splinted tube
37 Elasticring Elastic ring
38 1009803829 Spring
39 1039804385 Spring
40 Elasticring Elastic ring
41 Ocircle O circle
42 Ocircle O circle
43 Elasticring Elastic ring
44 Clamp Clamp
45 1009803830 Washer
46 Stoppingnut Stopping nut
47 Bolt Bolt
48 Ocircle O circle
49 Themotortakesoverabusiness The motor takes over a business
50 Bolt Bolt
51 Ocircle O circle
52 Dustcap Dust cap
70 Primaryplanetcarrierassy Primary planet carrier assy
71 Secondaryplanetcarrierassy Secondary planet carrier assy
72 Thirdplanetcarrierassy Third planet carrier assy
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
