Каталог запасных частей к технике: Zoomlion ZCC1100H. TRAVELING REDUCER D1030200733_100013Y

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
11
11
12
12
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
43
44
45
46
47
Позиция на иллюстрации Заводской номер детали Название детали
1030200733 1030200733 Traveling reducer
1 1009803766 Connecting shaft
2 1009803789 Bearing
3 1009803780 Retainer ring for hole
4 1009803775 Spring bearer plate
5 1039800904 Spring
6 1039800903 Spring
7 1009803795 X-ring
8 1009803782 Nylon retainer ring
9 1009803769 Adjusting washer
10 1009803794 Moving plate
11 1039800898 Hexagon socket plug
12 1039800651 Seal ring
13 1009803792 Hexagon socket plug
14 1009803783 Sealing ring
15 1009803791 Conical roller bearing
16 1009803787 O-ring
17 1009803784 Oil seal
18 1009803767 Bearing seat
19 1009803790 Conical roller bearing
20 1009803774 Locking nut
21 1009803771 Positioning sleeve
22 1009803770 Primary central gear ring washer
23 Primaryreductiongear Primary reduction gear assy
24 Secondaryreductiongear Secondary reduction gear assy
25 Thirdreductiongear Third reduction gear assy
26 1009803786 O-ring
27 1039803252 Gear ring
28 1009803785 O-ring
29 1039805812 Rear cover
30 1039800661 Plug
31 1009803776 Hexagon socket screw
32 1039801682 Elastic washer
33 1009803788 Bearing
34 1009803779 Retainer ring for shaft
35 1009803781 Retainer ring for hole
36 1009803755 Positioning pin
37 1009803777 Hexagon socket screw
38 1009803778 Elastic washer
39 1039801860 Hexagon socket screw
40 1009803798 Dust cap of oil seal
41 1009803772 Large flange
42 1039800900 Ventilation plug
43 1009803768 Limit washer
44 1009803793 Fixing plate
45 1039801871 Nylon retainer ring
46 1039800667 X-ring
47 1009803765 Piston
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
