Каталог запасных частей к технике: Zoomlion RT-551 (4x4). WINCH REDUCER D1030200945_100014Y

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
41
42
43
44
45
46
47
48
49
50
51
Позиция на иллюстрации Заводской номер детали Название детали
1030200945 1030200945 Winch reducer
1 1039800857 Bearing support
2 1039800892 Bearing
3 1039800850 Bearing cap
4 1039800879 Circlip
5 1039800873 Hexagon bolt
6 1039800878 Spring washer
7 1039802448 Locknut
8 1039802426 Primary central gear
9 1039802427 1-stage planetary wheel
10 1039802428 Cylindrical roller bearing
11 1039802429 Circlip for shaft
12 1039802430 Primary planetary carrier
13 1039802431 Primay planetary gear shaft
14 1039802432 Large flange
15 1039800901 Brake pipe
16 1039800875 Combination sealing element
17 1039802293 Ventilation plug
18 1039802294 X-ring
19 1039800884 Nylon retaining ring
20 1039802433 Piston
21 1039802295 X-ring
22 1039800885 Nylon retaining ring
23 1039802296 Plate
24 1039802297 Circlip
25 1039802434 Brake coupling
26 1039800889 O-ring
27 1039800903 Spring
28 1039800904 Spring
29 1039802435 Brake adjusting washer 2
30 1039800906 Stator plate
31 1039800907 Friction lining
32 1039802436 Brake adjusting washer 1
33 1039800897 Hexagon socket plug
34 1039800886 Seal ring
35 1039802422 1-stage planetary wheel
36 1039802423 Cylindrical roller bearing
37 1039802424 Circlip for shaft
38 1039802421 Primary central gear
39 1039800648 Retaining ring for shaft
40 1039802481 Oil seal
41 1039802482 Bearing
42 1039802483 Hexagon screw
43 1039802484 Large bearing seat
44 1039802486 O-ring
45 1039804741 Ring gear
46 1039802487 O-ring
47 1039802488 Rear cover
48 1039800869 Hexagon screw
49 1039800640 Spring washer
50 1039802489 Drum
51 1039800858 Support shaft
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
