Каталог запасных частей к технике: Zoomlion RT-100. JIB

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
2
3
4
4
4
4
4
5
5
5
5
5
6
6
6
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
20
21
21
22
23
24
25
26
27
28
28
28
29
30
31
32
33
34
34
35
35
35
35
36
36
37
37
37
37
37
38
38
39
40
40
40
40
41
41
42
42
43
43
44
45
46
47
48
49
53
53
54
54
Позиция на иллюстрации Заводской номер детали Название детали
00756300200000000 00756300200000000 Jib
1 00755900200001011 Pin
2 006340000001 Spring-loaded pin
3 00756300200200000 Adaptor
4 00755900200001020 Pin
5 1040500217 Pin
6 00756300200001010 Washer
7 00756300200001020 Stop plate
8 1040200097 Nut
9 1040300038 Washer
10 00756300200001030 Wedge
11 00756300200001040 Positioning pin
12 00756300200001050 Pad
13 00756300200400000 Box-shaped jib
14 00756300200600000 Lattice jib
15 00755908800001170 Pin
16 00755908800001180 Washer
17 00755908800001190 Wedge sleeve
18 00755908800001200 Wedge
19 1990200935 Wire rope clamp
20 00756300200001060 Rope guard pin
21 006340000032 Spring-loaded pin
22 00755900200001070 Pin
23 00756300200001070 Plate
24 00756300200800000 Pull bracket
25 1040000016 Bolt
26 1040200110 Nut
27 1040300052 Washer
28 1040300065 Washer
29 00756300201000000 Supporting roller
30 00756300200001080 Slide block
31 00756300200001090 Plate
32 00756300200001100 Shim
33 1040300054 Washer
34 1040000093 Bolt
35 00756300200001110 Sheath
36 00756300200001120 Shaft
37 006340000006 Spring-loaded pin
38 00756300201200000 Drum
39 00756300201400000 Pin
40 00755900200001160 Shaft ring
41 00755900202000000 Pulley assy
42 00755900202200000 Shaft
43 1040000132 Bolt
44 00756300200001130 Plate
45 00756300200001140 Spacer sleeve
46 00756308900600000 Pulley assy
47 00756300200001150 Hollow shaft
48 1040300107 Retainer ring
49 00756300200001160 Stop plate
50 204110014 Lithium-based Grease
51 202230025 Seal glue
52 00755901310001010 Wire rope
53 1999900003 Key ring
54 00755900230400000 Pin
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
