Каталог запасных частей к технике: Zoomlion PL2304. 015723058LC000000_05 Rear Hitch & Remote Output Pipeline
2
3
4
14
75
77
150
156
165
168
168
170
179
185
189
189
190
191
191
192
250
418
462
509
519
520
521
524
525
527
708
715
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2 | 1010001493 | Variable pump | |
| 3 | 1010309386 | Check Valve | |
| 4 | 1010304826 | Main valve | |
| 14 | 1010201293 | Lift cylinder | |
| 75 | 1149800691 | Oil Pot | |
| 77 | 1149800688 | Dust Proof Cap | |
| 150 | 1140109572 | Elbow | |
| 156 | 1149900368 | Tee union | |
| 165 | 1140112634 | Fitting | |
| 168 | 1140108807 | Fitting | |
| 170 | 1149900358 | Fitting | |
| 179 | 1140112426 | Tee union | |
| 185 | 1140112482 | Male Stud Coupling | |
| 189 | 1140108869 | High Pressure Banjo Coupling | |
| 190 | 1140108849 | Adjustable Elbow | |
| 191 | 1149901302 | Male Stud Coupling | |
| 192 | 1140112425 | Quick Coupling | |
| 250 | 1149900352 | Fitting | |
| 418 | 1990201939 | Clamp | |
| 462 | 1140113105 | Pipe clamp CL12-18 | |
| 509 | 01572104205090004 | Rigid tubing assembly | |
| 519 | 01572104205190002 | Rigid tubing assembly | |
| 520 | 01572104205200002 | Rigid tubing assembly | |
| 521 | 01572104205210003 | Rigid tubing assembly | |
| 524 | 01572104205240003 | Rigid tubing assembly | |
| 525 | 01572104205250001 | Rigid tubing assembly | |
| 527 | 01572104205270004 | Rigid tubing assembly | |
| 708 | 1140239777 | Hose assembly | |
| 715 | 015723058LC620000 | Variable displacement pump oil outlet hose assembly |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
