Каталог запасных частей к технике: Zoomlion PL2304. 015723058LC000000_03 Braking Pipeline
1
2
3
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 1140239769 | Hose assembly | |
| 2 | 015723058LC222000 | Booster return hose assembly | |
| 3 | 015723058LC223000 | Booster oil hose assembly | |
| 4 | 1149900387 | Adjustable Euqal Tee | |
| 5 | 1140112473 | Male Stud Coupling | |
| 6 | 1140108798 | Male Stud Coupling | |
| 7 | 1019901929 | Twin tandem booster | |
| 8 | 1140112474 | Male Stud Coupling | |
| 9 | 1140242715 | Hose assembly | |
| 10 | 1010800168 | Accumulator | |
| 11 | 1140108781 | Fitting | |
| 12 | 1149900353 | Fitting | |
| 13 | 01572104201240001 | Rigid tubing assembly | |
| 14 | 015723058LC020009 | Double pipe clamp | |
| 15 | 015723058LC020008 | Double pipe clamp | |
| 16 | 01572104201220002 | Rigid tubing assembly | |
| 17 | 1010307211 | Check Valve | |
| 18 | 01572104201210002 | Rigid tubing assembly | |
| 19 | 01572104201230002 | Rigid tubing assembly | |
| 20 | 1140112510 | Male Stud Coupling | |
| 21 | 1149900354 | Fitting | |
| 22 | 1140108779 | Male Stud Coupling | |
| 23 | 1149901310 | Test Coupling | |
| 24 | 1149900335 | Male Stud Coupling | |
| 25 | 1040000116 | Bolt | |
| 26 | 015723058LC020011 | pipe clamp | |
| 27 | 015723058LC020022 | U-clamp 6 | |
| 28 | 1040300067 | Washer | |
| 29 | 1040200113 | Nut | |
| 30 | 015723058LC020001 | Single hole pipe clamp | |
| 31 | 1140243708 | Hose assembly | |
| 32 | 1140112635 | Rigid tubing assembly | |
| 33 | 01572104201250001 | Rigid tubing assembly |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
