Каталог запасных частей к технике: Zoomlion K56X-6RZ. Vents layout on oil tank 001619118A0105000
1
2
3
3
3
3
3
4
5
5
5
5
6
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
23
23
24
25
25
25
26
26
26
27
27
27
27
27
28
28
28
28
28
29
29
30
30
30
30
30
30
30
30
30
31
32
32
33
33
34
35
36
37
38
39
40
40
41
42
42
43
44
45
46
47
48
49
50
51
52
53
53
54
55
55
56
57
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 1081000474 | O-ring | |
| 2 | 001605118А0000001 | Flange plate | |
| 3 | 1040300067 | Washer | |
| 4 | 1040100071 | Screw | |
| 5 | 1040000114 | Bolt | |
| 6 | 1040300061 | Washer | |
| 7 | 1140101630 | Flange half | |
| 8 | 1040300054 | Washer | |
| 9 | 1040000575 | Bolt | |
| 10 | 000198930А0600008 | Flange joint | |
| 11 | 1081000569 | O-ring | |
| 12 | 001600003А0000308 | Return transition flange | |
| 13 | 1040100073 | Screw | |
| 14 | 1040300063 | Washer | |
| 15 | 001605120А0000004 | Seal gasket | |
| 16 | 001605120А0000002 | Transition flange plate | |
| 17 | 1040000304 | Bolt | |
| 18 | 1040200100 | Nut | |
| 19 | 1040100637 | Screw | |
| 20 | 1040300045 | Washer | |
| 21 | 1040300044 | Washer | |
| 22 | 001605120А0020000 | Cover of airfilter | |
| 23 | 1140103506 | Straight joint | |
| 24 | 001607219А0050000 | Diffuser | |
| 25 | 1140101724 | Straight joint | |
| 26 | 1081000488 | Rhombus seal | |
| 27 | 1081000485 | Rhombus seal | |
| 28 | 1140101567 | Screw plug | |
| 29 | 1140101559 | Screw plug | |
| 30 | 1081000487 | Rhombus seal | |
| 31 | 1140101568 | Screw plug | |
| 32 | 1081000467 | O-ring | |
| 33 | 001613918А0001001 | Transition flange board | |
| 34 | 001607249А0010000 | Suction joint of inclined shaft pump | |
| 35 | 1081000475 | O-ring | |
| 36 | 000198930А1200001 | Temperate sensor transit joint | |
| 37 | 1140101583 | Screw plug | |
| 38 | 1081000479 | Rhombus seal | |
| 39 | 000198930А0600022 | Flange joint | |
| 40 | 000198930А0100026 | Straight joint | |
| 41 | 1081000483 | Rhombus seal | |
| 42 | 000198930А0100048 | Straight joint | |
| 43 | 000198930А0100024 | Straight joint | |
| 44 | 1140102198 | Straight joint | |
| 45 | 001605119А0030000 | Suction joint of constant pressure valve | |
| 46 | 000198930А0100021 | Straight joint | |
| 47 | 001618218А0005001 | Flange cover | |
| 48 | 001605149А0000005 | Offlet joint | |
| 49 | 1081000085 | Combination seal washer | |
| 50 | 1010300520 | Ball valve | |
| 51 | 000198930А1200016 | Offlet joint | |
| 52 | 1140101566 | Screw plug | |
| 53 | 000198931А1200005 | Screw plug | |
| 54 | 1140102938 | Straight joint | |
| 55 | 001607218А0020000 | Drainage device | |
| 56 | 001600003А0000305 | Pressure joint | |
| 57 | 1040100054 | Screw |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
