Каталог запасных частей к технике: Zoomlion 47X-5RZ. LUBRICATION SYSTEM
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
17
18
19
20
21
21
22
22
23
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
52
53
54
55
56
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 001692401A0000024 | Straight soft pipe | |
| 2 | 001692401A0000026 | Hose | |
| 3 | 1140101502 | L quick joint | |
| 4 | 1019900038 | Pressure gauge | |
| 5 | 1019900039 | Voltage regulator | |
| 6 | 1140101551 | Double worm joint | |
| 7 | 1000200034 | Muffler | |
| 8 | 1010300512 | Solenoid valve | |
| 9 | 1029900009 | Electromagnetic coil | |
| 10 | 1040100353 | Screw | |
| 11 | 1040300060 | Washer | |
| 12 | 1140101644 | Double worm joint ESK | |
| 13 | 1140101415 | T-shaped connector | |
| 14 | 1140101645 | Double external thread joint | |
| 15 | 1010300601 | Sphere valve | |
| 16 | 1140101413 | Reducing joint | |
| 17 | 1140101501 | L-quick joint | |
| 18 | 001692401A0000020 | Straight soft pipe | |
| 19 | 1070000000 | Pneumatic lubrication pump set | |
| 20 | 1040100122 | Screw | |
| 21 | 1040300063 | Washer | |
| 22 | 1040100272 | Screw | |
| 23 | 1040300062 | Washer | |
| 24 | 1080400017 | 90° curved core | |
| 25 | 1080400021 | Worm pipe sleeve | |
| 26 | 001692401A0000021 | High-pressure hose | |
| 27 | 001692401A0000022 | Protective cover | |
| 28 | 1080400016 | 90°expanding core | |
| 29 | 1140101506 | Tapered thread direct head | |
| 30 | 1010600044 | Mesh filter | |
| 31 | 1140101505 | Angled joint | |
| 32 | 001692401A0000023 | Bronze pipe | |
| 33 | 001692401A0000004 | Soleplate of 1st clamp | |
| 34 | 001692401A0000005 | Cover of 1st clamp | |
| 35 | 1040000151 | Bolt | |
| 36 | 001692401A0000006 | Two-pipe clamp bottom plate | |
| 37 | 001692401A0000007 | Two pipe clamp cover plate | |
| 38 | 001692401A0000008 | Three-pipe clamp bottom plate | |
| 39 | 001692401A0000009 | Three-pipe clamp cover plate | |
| 40 | 1080400020 | Eight-point progressive distributor assembly | |
| 41 | 001692401A0000010 | Four-pipe clamp bottom plate | |
| 42 | 001692401A0000011 | Four-pipe clamp cover plate | |
| 43 | 001692401A0000012 | Mounting bracket | |
| 44 | 001692401A0000013 | Extension connector 1 | |
| 45 | 001692401A0000014 | Extension joint 2 | |
| 46 | 1081000560 | Combined seal washer | |
| 47 | 1040100024 | Screw | |
| 48 | 001692401A0000015 | Two-wire distributor mounting plate | |
| 49 | 001692401A0000016 | Three-way connector for refueling point | |
| 50 | 1080000007 | Oil cup | |
| 51 | 1080400018 | Double wire distributor | |
| 52 | 001692401A0000017 | Screw plug | |
| 53 | 1081000480 | Rhombus seal | |
| 54 | 1140101461 | End straight coupling | |
| 55 | 1080400015 | Straight expanding core | |
| 56 | 001692405A0000001 | Nipple block | |
| 57 | 001692405A0000002 | Nipple block |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
