Каталог запасных частей к технике: Zoomlion 47X-5RZ. DISTRIBUTING VALVE SYSTEM

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
71
72
73
74
75
76
76
77
77
78
79
80
80
81
81
82
82
83
84
85
86
87
87
88
89
90
Позиция на иллюстрации Заводской номер детали Название детали
1 001693301A0009000 Coupling
2 001690201A0300000 150b type end cap
3 001693301A0009005 Sealing ring
4 001690201C0400000 Bend pipe
5 1040000505 Pillar bolt
6 1040200097 Nut
7 1040300038 Washer
8 000190201A0000019 Screw cap
9 1040100259 Screw
10 1040300054 Washer
11 1081000468 O-ring
12 001690201A0100000 Discharge port
13 000190201A0000008 Yx sealing ring
14 1081000456 O-ring
15 000190201A0000010 Retaining ring
16 000190201A0000009 Bearing
17 000190201A0000007 J-type dust ring
18 000190201A0000018 Bearing seat
19 001690201A0000012 Cushion cover 2
20 001690201A0000001 Cushion cover
21 1080000007 Oil cup
22 1040000104 Bolt
23 1040300063 Washer
24 001690201A0000007 Limit plate
25 000190201A0000016 Adjusting gasket
26 000190201A0000014 Spherical bearings
27 000190201A0300000 Right swing cylinder
28 001690201A0000006 Rubber spring
29 001690201A0000000 Distribution valve assembly
30 001690201A0000004 Glasses plate
31 1081000469 O-ring
32 001690201A0000002 Transition set
33 1040000484 Bolt
34 1040300065 Washer
35 1081000458 O-ring
36 000190201A0000013 Rocker arm
37 1040000114 Bolt
38 1040300067 Washer
39 000190201A0000022 Nut
40 000190201A0000023 Stopper
41 1040000098 Bolt
42 000190201A0000017 Limit plate
43 000190201A0000029 Key
44 1040100348 Screw
45 1040300044 Washer
46 000190201A0000024 Bushing
47 1081000429 O-ring
48 000190201A0000025 Collar
49 000190201A0000028 Screw plug
50 000190201A0000027 Positioning pin
51 001690201A0000009 Washer
52 1040100381 Screw
53 000190201A0000026 End face bearing
54 000190201A0200000 Left swing cylinder
55 000190201A0000021 Bearing seat
56 1081000442 O-ring
57 000190201A0000033 Retaining ring
58 000190201A0000032 Du bearing
59 000190201A0000031 Yx type sealing ring
60 000190201A0000030 J-type dust ring
61 1081000551 O-ring
62 001690201A0201000 S pipe valve
63 000190201A0000020 Movable scraper
64 1040000149 Bolt
65 1040200096 Nut
66 001690201A0000010 Pin shaft
67 1040500217 Pin
68 000190201A0100001 Bushing
69 001690201A0000011 Oblique block
70 000190201A0000011 Set
71 000190201A0300001 Piston rod
72 1040100482 Screw
73 1081200129 Dustproof ring A1
74 1081000493 Seal of piston rod
75 1081400502 FR guide ring
76 1040100343 Screw
77 1040300054 Washer
78 000190201A0300002 Guide sleeve
79 1081000434 O-ring
80 000190201A0300003 Retaining ring
81 1081000439 O-ring
82 1081400511 FR guide ring
83 1081000506 OK piston seal
84 000190201A0300007 Piston
85 000190201A0301000 Oil cylinder block
86 1010300514 Check valve
87 000190201A0300004 Cylinder head flange
87 000190201A0200001 Cylinder head flange
88 1081000424 O-ring
89 000190201A0300005 Lock nut
90 000190201A0300006 Adjusting bolts
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
