Каталог запасных частей к технике: Yuchai YC55. HYDRAULIC SYSTEM FOR PLATFORM 2
1
2
2
3
3
4
5
5
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
19
20
20
20
20
21
22
23
24
25
26
27
28
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 850-0512000 | Steel tube assembly | |
| 2 | 850-0500007 | Bolt tie-in | |
| 3 | GB3452.1 | O-ring | |
| 4 | PVK-2B-505 | Pump | |
| 5 | GB342.1 | O seal ring | |
| 6 | 850-0511000 | Steel tube assembly | |
| 7 | GB/T93 | Washer | |
| 8 | GB/T70 | Bolt | |
| 9 | JB/ZQ3777 | Hoop | |
| 10 | 850-0500009 | Transport oil rubber pite | |
| 11 | 850-0503000 | Oil box | |
| 12 | 850-0519000 | Steel tube assembly | |
| 13 | GB/T93 | Washer | |
| 14 | GB5783 | Bolt | |
| 15 | 850-0531000 | Rubber pipe assembly | |
| 16 | 850-0513000 | Steel tube assembly | |
| 17 | DPK-T04-9P | Multi-change valve | |
| 18 | ICI-36-16B | Right angle tie-in | |
| 19 | 850-0532000 | Rubber pipe assembly | |
| 20 | JB/ZQ3777 | Hoop | |
| 21 | 850-0500017 | Rubber pipe | |
| 22 | 850-0518000 | Steel tube assembly | |
| 23 | 850-0500006 | Bolt tie-in | |
| 24 | JB982 | Combintory washer | |
| 25 | 850-0516000 | Valve | |
| 26 | 850-0500008 | Rubber pipe | |
| 27 | 850-0517000 | Steel tube assembly | |
| 28 | 850-0509000 | Radiator | |
| 29 | GB/T97.1 | Washer | |
| 30 | GB/T5783 | Bolt |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
