Каталог запасных частей к технике: YTO ZL50F. On-vehicle Tools
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 654.49.627-1 | Hex-socket S36 | |
| 2 | Double-hex-socket 14x17 | Double-hex-socket 14x17 | |
| 3 | GB1164-1989 | Butter nipple (A nipple) | |
| 4 | GB/T5356-1998 | Inner-hex-socket spanner 6 | |
| 5 | GB/T5356-1998 | Inner-hex-socket spanner 10 | |
| 6 | GB/T5356-1998 | Inner-hex-socket spanner 12 | |
| 7 | GB/T4388-1995 | Double-end spanner 50x55 | |
| 8 | GB/T4388-1995 | Double-end spanner 41x46 | |
| 9 | GB/T4388-1995 | Double-end spanner 32x36 | |
| 10 | GB/T4388-1995 | Double-end spanner 27x30 | |
| 11 | GB/T4388-1995 | Double-end spanner 22x24 | |
| 12 | GB/T4388-1995 | Double-end spanner 17x19 | |
| 13 | GB/T4388-1995 | Double-end spanner 12x14 | |
| 14 | GB/T4388-1995 | Double-end spanner 9x11 | |
| 15 | GB/T4388-1995 | Double-end spanner 8x10 | |
| 16 | GB10639-1989 | Screwdriver 250x8 | |
| 17 | GB4440-1984 | Adjusting spanner 300x36 | |
| 18 | A49-C5A | Hammer 0.8kg | |
| 19 | GB/T2349-1997 | Wire-cutter 200 | |
| 20 | Cold chisel | Cold chisel | |
| 21 | Charge air pipe | Charge air pipe |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
