Каталог запасных частей к технике: YTO ZL50F. Gearbox (VII) Speed Change Valve
1
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
30
31
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 403702 | Bolt | |
| 2 | 402106 | Washer | |
| 3 | 403701A | Valve | |
| 4 | 403727 | Manometer tie-in | |
| 5 | 403704 | Reduce pressure valve rod | |
| 6 | 403725 | Spring seat | |
| 7 | 403724 | Spring | |
| 8 | 403723 | Lock cover | |
| 9 | 403722 | Piece | |
| 10 | 403721 | Washer | |
| 11 | 403720 | Screw plug | |
| 12 | 403706 | Spring | |
| 13 | 403705 | Brake valve rod | |
| 14 | 403718 | Column plug | |
| 15 | GB1235-76 | O ring 103x5.7 | |
| 16 | 403719 | Bolt | |
| 17 | 403717 | Nut | |
| 18 | 403712 | Air valve seat | |
| 19 | 403714 | Spring | |
| 20 | 403713 | Air valve rod | |
| 21 | 403715 | Y sealing ring 32x40 | |
| 22 | 403716 | Air valve body | |
| 23 | 403708 | Allocation valve rod | |
| 24 | 403711 | Retaining cover | |
| 25 | GB1235-76 | O ring 103x5.7 | |
| 26 | JB2600-80 | Framework oil sealing | |
| 27 | GB893.1-86 | Retaining ring 30 | |
| 28 | Plastic ball 3/16 | Plastic ball 3/16 | |
| 29 | 403726 | Round board | |
| 30 | GB308-84 | Steel ball 12.7 | |
| 31 | 403707 | Spring | |
| 32 | 402001 | Washer | |
| 33 | 403710 | Bolt |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
