Каталог запасных частей к технике: YTO X1204. Transfer case assembly

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1.1
1.2
2
3
4
5
6
7
7
8
9
10
11
12
13
14
15
16
17
18
19
20
41
41
Позиция на иллюстрации Заводской номер детали Название детали
1 4994264/1.33.002A PTO Housing with dowel pin
1.1 GB 119-86 Pin A10x30
1.2 SZ1204.42.101 Housing, PTO
2 GB 5786-86 Bolt M12x1.25x60
3 10263420/14607 Rectangular cross-section seal washer
4 10275001/14534 Drain plug M22x1.5
5 BZ/JHX-SZ Pin 5x30
6 4994227/1.33.112 Shaft, gear, lead out device
7 1204.42.108 Thrust washer, idler, lead out device
8 1204.42.109 Washer, needle bearing, planetary gear
9 5104120/1.48.172 Roller bearing
10 1204.42.102 Idler, PTO shaft, lead out device
11 12043.38.109SZ Driving gear, PTO
12 GB/T283-1994 Bearing NUP211E(92211E)
13 1204.42.104 Driven shaft, lead out device
14 1204.42.101 Driven shaft, lead out device
15 11069576/12245 Circlip 55
16 4994233/1.33.136 Oil baffle disc, bearing, lead out device
17 GB/T276-1994 Bearing 6206E(206)
18 11062476/12246 Circlip90
19 5129003/1.33.135 Oil seal 55x90x10, lead out shaft
20 4994297/1.33.145 Oil seal disc
21 5136799/1.80.266 Handle assembly
22 GB 845-85 Tapping screw
23 GB 818-85 Bolt M6x22
24 4998311/1.80.255 Ball socket
25 5109058/1.80.254 Ball socket
26 GB 7244-87 Washer 18-Zn.D
27 GB 6170-86 Nut M8
28 1204-1.42.011 Control lever unit, lead out device
29 GB 91-86 Pin 6.3x26
30 GB 97.1-85 Washer 12-Zn.D
31 5129442/1.80.268 Bushing, outer lever
32 5131536/1.33.234 Outer drive link, lead out device control
33 4997638/1.33.228 Locking screw, inner lever
34 10280060/14607 Rectangular gasket
35 4966305/1.80.841 Spring
36 5112851/1.33.226 Locking detent, inner lever
37 5101312/1.33.222A Inner drive link unit, lead out device control
38 885100858/1.33.237 Shift block, PTO control
39 BZ/JHX-SZ Pin 5x30
40 559983/1.80.232 Oil seal, shaft, dowel bar
41 1204.42.108-1 Thrust washer, idler, lead out device
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
