Каталог запасных частей к технике: YTO X1204. Steering box assembly
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 1204-1.40.017 | Steering wheel assembly | |
| 2 | GB/T6173-2000 | Nut M10x1.25 | |
| 3 | GB/T894.1-1986 | Circlip 6 | |
| 4 | 11060276/12246 | Retainer ring D=47 | |
| 5 | GB/T276-1994 | Bearing 6206E(206) | |
| 6 | 1204-1.40.011-1 | Sleeve unit | |
| 7 | GB/T5783-2000 | Bolt M12x40-Zn.D | |
| 8 | GB/T7244-1987 | Washer 8-Zn.D | |
| 9 | 1204-1.40.107-1 | Splined steering shaft | |
| 10 | 1204-1.40.115 | Anti-friction sleeve | |
| 11 | GB/T893.1-1986 | Circlip 34 | |
| 12 | 5127283/1.62.0 | Gasket | |
| 13 | 5127284/1.62.0 | Gasket | |
| 14 | 5124930/1.62.0 | Bracket assembly, steering column | |
| 15 | 5110738/1.62.061 | Pin, support | |
| 16 | 1204-1.40.102 | Sleeve | |
| 17 | GB/T5783-2000 | Bolt M12x40-Zn.D | |
| 18 | GB/T97.1-1985 | Washer 20 | |
| 19 | 1204-1.40.118 | Set lever unit | |
| 20 | 1204-1.40.103 | Nut | |
| 21 | 1204-1.40.118 | Washer | |
| 22 | 1204-1.40.117 | Washer | |
| 23 | GB/T848-1985 | Washer 14-Zn.D | |
| 24 | GB/T889-1986 | Nut M8-Zn.D | |
| 25 | 1204-1.40.104 | Bolt | |
| 26 | 1204-1.40.012 | Bracket unit | |
| 27 | 1204-1.40.112A | Bracket, fuse block | |
| 28 | GB/T93-1987 | Washer 12-Zn.D | |
| 29 | GB/T5783-2000 | Bolt M12x40-Zn.D | |
| 30 | GB/T6187-1986 | Nut M8x5-Zn.D | |
| 31 | GB/T5783-2000 | Bolt M12x40-Zn.D | |
| 32 | 1204-1.40.015 | Universal joint | |
| 33 | GB/T5783-2000 | Bolt M12x40-Zn.D | |
| 34 | GB/T93-1987 | Washer 12-Zn.D | |
| 35 | GB/T97.1-1985 | Washer 20 | |
| 36 | 5119125/1.87.038 | Pad unit | |
| 37 | 5124936/1.62.0 | Bushing, hydraulic steering gear | |
| 38 | 5124937/1.62.0 | Backing plate, hydraulic steering gear | |
| 39 | 1204-1.40.010 | Steering gear assembly |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
