Каталог запасных частей к технике: YTO X1204. Front axle assembly

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
10.1
10.2
11
11
12
12.1
12.1
12.2
12.2
12.3
12.4
12.4
12.4
12.4
12.4
12.4
12.4
12.4
12.4
12.5
12.6
12.7
12.8
13
Позиция на иллюстрации Заводской номер детали Название детали
1 5143242/16 Locking nut
2 4997451/1.41.143 Collar, oil seal
3 5135294/16 Oil seal 45x75x10
4 GB/T 3452.1-1992 O-sealing ring 31.5x1.8
5 GB/T 308-1994 Steel ball 6.35
6 5142026/16 Oil seal ring, shaft, bevel pinion
7 5133776/16 Rear bearing
8 5143109/16 Bearing (FR)
9 5142032/16 Adjusting washer 3.0mm
10 20105010060 Bevel gear pair 13/43
10.1 5142248/16 Shaft, bevel pinion
10.2 5140753/16 Bevel gear wheel
11 GB/T 297-1994 Bearing 32012 (60x95x23)
12 5117219/1.41 Differential assembly
12.1 4987975/1.32.425 Thrust washer, planetary gear
12.2 885103870/1.32.415B Planetary gear
12.3 5148935/1.32.416 Shaft, pinion, differential
12.4 5148936/1.32.424 Thrust washer, side gear 1.6 mm
12.4 5148937/1.32.424 Thrust washer, side gear 1.8 mm
12.4 5148938/1.32.424 Thrust washer, side gear 1.7 mm
12.5 885103868/1.32.413 Side gear (LH)
12.6 885110716/1.41.502 Side gear (RH)
12.7 4996747/1.41.402 Carrier, differential
12.8 4987976/1.32.428 Dowel
13 14274434/10357/04 Bolt M12x1.25x25
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
