Каталог запасных частей к технике: YTO KC125 Мост. Steering cylinder assembly
1
1
2
2
2
2
3
3
4
4
4
4
5
5
6
6
7
7
7
7
8
8
8
8
9
9
10
10
11
11
12
12
13
14
15
16
17
18
18
19
19
20
20
21
21
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 240100013400 | Retaining ring | |
| 2 | 240100029628 | Cylinder pin washer | |
| 3 | 240100029625 | Cylinder pin | |
| 4 | 210715000015 | Oil cup | |
| 5 | 240100117938 | Clamp | |
| 6 | 240100010725 | Steering cylinder | |
| 7 | 210501000004 | Combination gasket | |
| 8 | 240100009682 | Air core bolt | |
| 9 | 240100029671 | Cylinder pin assembly | |
| 10 | 210110330003 | Washer | |
| 11 | 210101280089 | Bolt | |
| 12 | 240100029672 | Spacer | |
| 13 | 240100209241 | Left cylinder, left turn, oil pipeline assembly | |
| 14 | 240100209242 | The left cylinder turns to the right to the oil pipeline assembly | |
| 15 | 240100180139 | Cylinder hose | |
| 15.5 | 240100180139 | Cylinder hose | |
| 16 | 240100010568 | Right cylinder, left turn, oil pipeline assembly | |
| 17 | 240100010564 | Right cylinder, right turn, oil pipeline assembly | |
| 18 | 210101280080 | Bolt | |
| 19 | 210110330016 | Washer | |
| 20 | 240100003713 | Tubing clip | |
| 21 | 240100029669 | Support plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
