Каталог запасных частей к технике: YTO KC125 Мост. Left wheel side reducer assembly
1
1.1
1.1
1.2
1.2.1
1.2.2
1.3
1.4
1.4.1
1.4.2
1.5
1.6
1.7
1.8
1.9
1.9
1.10
1.11
1.12
1.13
1.14
1.15
1.15.1
1.15.2
1.15.3
1.15.3
1.15.4
1.15.5
1.16
1.17
1.18
2
3
4
5
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 240100235441 | Left wheel side reducer assembly | |
| 1.1 | 210201000459 | Bearing | |
| 1.2 | 240100087459 | Front wheel hub with fixed pin | |
| 1.2.1 | 240100029864 | Front drive hub | |
| 1.2.2 | 240100002488 | Positioning pin | |
| 1.3 | 240100220920 | Front wheel hub oil seal | |
| 1.4 | 240100087707 | Left turn joint fitting | |
| 1.4.1 | 240100068142 | Left turn joint | |
| 1.4.2 | 240100002605 | Steering knuckle bushing | |
| 1.5 | 240100051762 | Spacer | |
| 1.5.1 | 240100029818 | Spacer | |
| 1.6 | 240100013313 | Bolt | |
| 1.7 | 240100140442 | Fork shaft oil seal | |
| 1.8 | 240100140442 | Fork shaft oil seal | |
| 1.9 | 240100008933 | Retaining ring | |
| 1.10 | 240100217140 | Sun wheel | |
| 1.11 | 240100029621 | Ring gear retaining ring | |
| 1.12 | 240100066747 | Ring gear support | |
| 1.13 | 240100066746 | Ring gear | |
| 1.14 | 240100029645 | Ring gear support nut | |
| 1.15 | 240100250623 | Planetary frame assembly | |
| 1.15.1 | 240100068134 | Planetary frame | |
| 1.15.2 | 240100012878 | Planetary gear shaft | |
| 1.15.3 | 240100013314 | Planetary gear bearing retaining ring | |
| 1.15.4 | 210205000006 | Needle roller | |
| 1.15.5 | 240100217139 | Planetary wheel | |
| 1.16 | 240100025771 | Self-locking screw | |
| 1.17 | 240100123036 | Combination gasket | |
| 1.18 | 240100009759 | Hexagonal screw plug | |
| 2 | 240100051761 | Kingpin ball hinge adjustment pad | |
| 3 | 240100029641 | Knuckle kingpin | |
| 4 | 240100025770 | Self-locking screw | |
| 5 | 210715000015 | Oil cup |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
