Каталог запасных частей к технике: XGMA XG958. HOOD AND HOUSING
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 06B0044 | Washer | |
| 2 | 06B0004 | Washer | |
| 3 | 06B0014 | Washer | |
| 4 | 06B0027 | Washer | |
| 5 | 06B0009 | Washer | |
| 6 | 06B0029 | Washer | |
| 7 | 06B0020 | Washer | |
| 8 | 22B0083 | Seal | |
| 9 | 20A0365 | Board | |
| 10 | 20A0366 | Board | |
| 11 | 20A0373 | Board | |
| 12 | 20A0375 | Board | |
| 13 | 20A0374 | Board | |
| 14 | 48C0113 | Air spring | |
| 15 | 44D0037 | Cover | |
| 16 | 44D0032 | Cover | |
| 17 | 44D0043 | Cover | |
| 18 | 44D0040 | Cover | |
| 19 | 44D0039 | Cover | |
| 20 | 05B0031 | Screw | |
| 21 | 00B0029 | Bolt | |
| 22 | 00B0111 | Screw | |
| 23 | 01B0155 | Screw | |
| 24 | 01B0156 | Screw | |
| 25 | 03B0034 | Nut | |
| 26 | 03B0013 | Nut | |
| 27 | 04B0059 | Screw | |
| 28 | 38A0107 | Pipe | |
| 29 | 48C0110 | Group of bars | |
| 30 | 08B0041 | Pin | |
| 31 | 08B0031 | Pin | |
| 32 | 48C0114 | Lock | |
| 33 | 44D0033 | Door | |
| 34 | 44D0034 | Door | |
| 35 | 44D0035 | Skeleton |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
