Каталог запасных частей к технике: XGMA XG955III. Working hydraulic system
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 10C0166 | Cylinder | |
| 2 | 33C0110 | Hose | |
| 3 | 17D0004 | Steel pipe joint | |
| 4 | 17D0282 | Steel pipe joint | |
| 5 | 17DO253 | Tube | |
| 6 | 33C0109 | Hose | |
| 7 | 58A0023 | Flange | |
| 8 | 33C0001 | Connector | |
| 9 | 10C0605 | Boom cylinder | |
| 10 | 17D0146 | Steel pipe joint | |
| 11 | 18D0040 | Steel pipe joint | |
| 12 | 08C0049 | Clamp | |
| 13 | 12C0139 | Valve | |
| 14 | 17D1002 | Steel pipe joint | |
| 15 | 06C1019 | Hose | |
| 16 | 17D1729 | Steel pipe joint | |
| 17 | 17D1885 | Steel pipe joint | |
| 18 | 82A0452 | Pipe clamps | |
| 19 | 17D1730 | Steel pipe joint | |
| 20 | 07C0083 | Hose fittings | |
| 21 | 07C0082 | Hose fittings | |
| 22 | 61C0005 | Трос управления гидравликой | |
| 23 | 24B0003 | Clamp | |
| 24 | 13B0023 | Hose | |
| 25 | 11C0095 | Gear pump | |
| 26 | 44C0199 | Hydaulic Control GOLD | |
| 27 | 17D1791 | Tube | |
| 28 | 07C0584 | Hose fittings | |
| 29 | 18D0039 | Steel pipe joint | |
| 30 | 07C0327 | Hose fittings | |
| 31 | 21C0313 | Oil tank | |
| 32 | 20C0120 | Radiator assembly | |
| 33 | 08C0126 | 08C0126 | |
| 34 | 08C0164 | 08C0164 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
