Каталог запасных частей к технике: XGMA XG955III. Total figure spare parts
1
2
3
4
5
6
6
6
7
8
9
10
11
12
15
15
16
17
18
19
20
20
21
22
23
24
24
25
26
27
28
30
31
32
33
34
35
36
37
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 17D0171 | Tube | |
| 2 | 02A0025 | Connector | |
| 3 | 20A0001 | plate | |
| 4 | 03B0005 | Nut | |
| 5 | 00B0018 | Bolt | |
| 6 | 06B0063 | Washer | |
| 7 | 17D0155 | Tube | |
| 8 | 17D0170 | Tube | |
| 9 | 05C0042 | Hose | |
| 10 | 55C0042 | Booster | |
| 11 | 03C0011 | Hose | |
| 12 | 12C0092 | Blake valve | |
| 15 | 00B0070 | Bolt | |
| 16 | 82A0001 | Clip | |
| 17 | 17D0157 | Tube | |
| 18 | 01C0018 | Tube | |
| 19 | 01C0043 | Tube | |
| 20 | 04C0027 | Hose | |
| 21 | 55C0043 | Air pressure source manager | |
| 22 | 56A0006 | Spacer | |
| 23 | 21A0403 | plate | |
| 24 | 00A0001 | Connector | |
| 25 | 01A0004 | Connector | |
| 26 | 03B0008 | Nut | |
| 27 | 04C0027 | Hose | |
| 28 | 14D0031 | Reservoir | |
| 30 | 82A0007 | Clip | |
| 31 | 17D0161 | Tube | |
| 32 | 02A0008 | Connector | |
| 33 | 46C0107 | Switch | |
| 34 | 03A0014 | Connector | |
| 35 | 03C0006 | Hose | |
| 36 | 02A0001 | Connector | |
| 37 | 03C0001 | Hose | |
| 38 | 55C0044 | Dish blake |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
