Каталог запасных частей к технике: XGMA XG955III. Car frame
1
2
2
5
9
9
9
9
10
10
10
11
12
12
12
12
12
13
14
15
16
17
18
19
20
21
21
22
22
23
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
43
44
44
45
45
46
46
47
48
48
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 00B0023 | Bolt | |
| 2 | 06B0013 | Washer | |
| 3 | 58A0089 | Flange | |
| 4 | 60A0069 | Shaft | |
| 5 | 01B0030 | Pin | |
| 6 | 12B0039 | Seal | |
| 7 | 58A0087 | Flange | |
| 8 | 35B0013 | Bearing | |
| 9 | 00B0016 | Bolt | |
| 10 | 06B0020 | Washer | |
| 11 | 06B0014 | Washer | |
| 12 | 06B0028 | Washer | |
| 13 | 11B0007 | Sleeve | |
| 14 | 58A0090 | Flange | |
| 15 | 35B0012 | Bearing | |
| 16 | 54A0109 | Sleeve | |
| 17 | 58A0091 | Flange | |
| 18 | 00B0O08 | Bolt | |
| 19 | 06B0005 | Washer | |
| 20 | 25C0009 | Hinge | |
| 21 | 00B0044 | Bolt | |
| 22 | 06B0001 | Lock washer | |
| 23 | 55A0020 | Spacer | |
| 24 | 58A0103 | Flange | |
| 25 | 60A0070 | Shaft | |
| 26 | 58A0088 | Flange | |
| 27 | 55A0083 | Spacer | |
| 28 | 55A0084 | Spacer | |
| 29 | 03B0108 | Nut | |
| 30 | 23A0175 | Plate | |
| 31 | 74A0007 | Fork | |
| 32 | 60A0027 | Pin | |
| 33 | 17A0072 | Plate | |
| 34 | 08B0007 | Pin | |
| 35 | 22A0042 | Plate | |
| 36 | 05B0037 | Bolt | |
| 37 | 06B0027 | Washer | |
| 38 | 03B0005 | Nut | |
| 39 | 15D0017 | Pin | |
| 40 | 57A0003 | Spring | |
| 41 | 00D0374 | Bracket | |
| 42 | 30D0048 | Rear Frame | |
| 43 | 54A0017 | Sleeve | |
| 44 | 55A0092 | Washer | |
| 45 | 15D0016 | Pin | |
| 46 | 54A0091 | Sleeve | |
| 47 | 00D1572 | Oscillate frame | |
| 48 | 00B0012 | Bolt |
