Каталог запасных частей к технике: XGMA XG955II. Driving room
47C0210
47C0158
40D0034
51B0047
47C0045
40D0032
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 47C0210 | 47C0210 | Door Group | |
| 47C0158 | 47C0158 | Right Battery Case | |
| 40D0034 | 40D0034 | Right Rear Fender | |
| 51B0047 | 51B0047 | Glass | |
| 47C0045 | 47C0045 | Lock | |
| 40D0032 | 40D0032 | Right Front Fender | |
| 1 | 86A0018 | Cab Cover | |
| 2 | 47C0209 | Door Group | |
| 3 | 51B0048 | Glass | |
| 4 | 47C0147 | Rear view mirror | |
| 5 | 47C0148 | lightproof Assem | |
| 6 | 47C0024 | Rear view mirror | |
| 7 | 47C0208 | Instrument Platform | |
| 8 | 47C0205 | Cab Group | |
| 9 | 05B0017 | Stud | |
| 10 | 06B0001 | Lock washer | |
| 11 | 03B0094 | Nut | |
| 12 | 22C0017 | Absorber | |
| 13 | 86A0013 | Booster Set Cover | |
| 14 | 00B0031 | Bolt | |
| 15 | 06B0013 | Washer | |
| 16 | 06b0120 | Washer | |
| 17 | 05B0011 | Stud | |
| 18 | 03B0010 | Nut | |
| 19 | 40D0031 | Left Front Fender | |
| 20 | 51B0051 | Glass | |
| 21 | 47C0044 | Door lock | |
| 22 | 51B0043 | Glass | |
| 23 | 05B0017 | Stud | |
| 24 | 06B0121 | Washer | |
| 25 | 06B0020 | Washer | |
| 26 | 03B0034 | Nut | |
| 27 | 47C0144 | Seat Assem | |
| 28 | 47C0145 | Seat Assem | |
| 29 | 40D0033 | Left Rear Fender | |
| 30 | 47C0152 | Lock | |
| 31 | 04B0095 | Serew | |
| 32 | 06B0009 | Washer | |
| 33 | 47C0157 | Left Battery Case |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
