Каталог запасных частей к технике: XGMA XG953III. Working hydraulic system
10B0003
60C0189
60C0175
60C0201
10B0011
10B0028
10B0115
10B0028
10B0003
10B0028
10B0003
10B0028
10B0003
10B0028
10B0028
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10B0003 | 10B0003 | О ring | |
| 60C0189 | 60C0189 | Oil return filter | |
| 60C0175 | 60C0175 | Oil suction filter | |
| 60C0201 | 60C0201 | Liquid Level Meter | |
| 10B0011 | 10B0011 | O Ring | |
| 10B0028 | 10B0028 | O Ring | |
| 10B0115 | 10B0115 | O Ring | |
| 10B0028 | 10B0028 | O Ring | |
| 10B0003 | 10B0003 | О ring | |
| 10B0028 | 10B0028 | O Ring | |
| 10B0003 | 10B0003 | О ring | |
| 10B0028 | 10B0028 | Type ring | |
| 10B0003 | 10B0003 | О ring | |
| 10B0028 | 10B0028 | O Ring | |
| 10B0028 | 10B0028 | O Ring | |
| 1 | 10C0030 | Bucket cylinder | |
| 2 | 17D1747 | Steel pipe joint | |
| 3 | 17D1749 | Steel pipe joint | |
| 4 | 06C0047 | Hose | |
| 5 | 17D0525 | Steel pipe joint | |
| 6 | 82A0127 | Pipe clamps | |
| 7 | 17D1751 | Steel pipe joint | |
| 8 | 11C0095 | Gear pump | |
| 9 | 17D0430 | Steel pipe joint | |
| 10 | 05C0015 | Hose | |
| 11 | 20C0120 | Radiator assembly | |
| 12 | 07C0573 | Hose | |
| 13 | 07C0572 | Hose | |
| 14 | 21C0290 | Hydraulic fuel tank | |
| 15 | 17D1726 | Steel pipe joint | |
| 16 | 17D1748 | Steel pipe joint | |
| 17 | 07C0568 | Hose | |
| 18 | 07C0567 | Hose | |
| 19 | 10C0556 | Boom cylinder | |
| 20 | 17D1672 | Steel pipe joint | |
| 21 | 23A1257 | Board | |
| 22 | 82A0452 | Pipe clamps | |
| 23 | 17D1670 | Steel pipe joint | |
| 24 | 06C1019 | Hose | |
| 25 | 17D1750 | Steel pipe joint | |
| 26 | 17D0423 | Steel pipe joint | |
| 27 | 17D1746 | Steel pipe joint | |
| 28 | 18D0084 | Steel pipe joint | |
| 29 | 07C0323 | Hose | |
| 30 | 07C0571 | Hose | |
| 31 | 17D0428 | Steel pipe joint | |
| 32 | 17D1671 | Steel pipe joint | |
| 33 | 17D1669 | Steel pipe joint |
