Каталог запасных частей к технике: XGMA XG953III. Foot brake
1
1
1
1
2
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
19
20
21
22
23
24
24
25
26
26
26
27
27
28
29
30
31
32
33
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 55C0044 | Dish blake | |
| 2 | 20A1908 | Cover | |
| 3 | 17D1701 | Tube | |
| 4 | 01C0016 | Tube | |
| 5 | 05C0042 | Hose | |
| 6 | 17D0019 | Tube | |
| 7 | 01C0019 | Tube | |
| 8 | 03C0001 | Hose | |
| 9 | 04C0019 | Hose | |
| 10 | 04C0027 | Hose | |
| 11 | 55C0033 | Valve | |
| 12 | 55C0031 | Reservoir group | |
| 13 | 01C0018 | Tube | |
| 14 | 02A0001 | Connector | |
| 15 | 01C0042 | Tube | |
| 16 | 17D0217 | Tube | |
| 17 | 82A0038 | Clip | |
| 18 | 00B0070 | Bolt | |
| 19 | 06B0009 | Washer | |
| 20 | 02A0008 | Connector | |
| 21 | 03C0026 | Hose | |
| 22 | 03C0005 | Hose | |
| 23 | 02A0025 | Connector | |
| 24 | 17D0114 | Tube | |
| 25 | 55C0004 | Blake valve | |
| 26 | 56A0006 | Spacer | |
| 27 | 01B0004 | Bolt | |
| 28 | 01A0004 | Connector | |
| 29 | 00B0073 | Bolt | |
| 30 | 55C0028 | Booster | |
| 31 | 17D0022 | Tube | |
| 32 | 55C0039 | Blake light switch | |
| 33 | 67A0001 | Connector | |
| 34 | 17D0020 | Tube | |
| 35 | 46C0107 | Switch |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
