Каталог запасных частей к технике: XGMA XG935H. Steering System
1
2
3
3
3
3
3
3
3
4
4
4
4
4
5
5
6
7
8
9
10
10
10
10
11
11
11
11
12
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 10C1190 | Cylinder | |
| 2 | 06С0054 | Hose | |
| 3 | 06В0003 | Washer | |
| 4 | 0080022 | Bolt | |
| 5 | 44С0095 | 44С0095 | |
| 6 | 30С0378 | Connector | |
| 7 | 06С2888 | Hose | |
| 8 | 30С0254 | Connector | |
| 9 | 05С0875 | Hose | |
| 10 | 06В0004 | Washer | |
| 11 | 10В0013 | Ring | |
| 12 | 30С0001 | Connector | |
| 13 | 17D1559 | Connector | |
| 14 | 10В0217 | O-Ring | |
| 15 | 44С0007 | 44С0007 | |
| 16 | 01В0038 | Bolt | |
| 17 | 30C0243 | Connector | |
| 18 | 17D3175 | Tube | |
| 19 | 28В0122 | Connector | |
| 20 | 17D3300 | Tube | |
| 21 | 06С0049 | Hose | |
| 22 | 01B0039 | Bolt | |
| 23 | 17D0329 | Connector | |
| 24 | 1ICO583 | Pump | |
| 25 | 05B0032 | Stud | |
| 26 | 06B0013 | Washer | |
| 27 | 03B0010 | Nut | |
| 28 | 14B0003 | gasket | |
| 29 | 07C0127 | Hose | |
| 30 | 24B0O46 | Clamp | |
| 31 | 00B0028 | Bolt | |
| 32 | 17D0330 | Tube | |
| 33 | 17D0426 | Tube | |
| 34 | 12C0689 | Valve | |
| 35 | 28B0002 | Connector | |
| 36 | 06C2292 | Hose | |
| 37 | 06C2197 | Hose | |
| 38 | 06C2293 | Hose | |
| 39 | 06C2198 | Hose |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
