Каталог запасных частей к технике: XGMA XG935H. Main Drive Gear
45A0022
45A0020
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 45A0022 | 45A0022 | Gear | |
| 45A0020 | 45A0020 | Gear | |
| 1 | 01B0092 | Bolt | |
| 2 | 06B0003 | Washer | |
| 3 | 14D0049 | Flange | |
| 4 | 55A0254 | Washer | |
| 5 | 03B0017 | Nut | |
| 6 | 10B0055 | O-ring | |
| 7 | 11B0024 | Seal | |
| 8 | 52A0313 | Cover | |
| 9 | 01B0D41 | Bolt | |
| 10 | 06B0013 | Washer | |
| 11 | 11B0234 | Shims | |
| 12 | 54A0305 | Sleeve | |
| 13 | 56A0091 | Shims | |
| 14 | 11B0235 | Shims | |
| 15 | 54A0306 | Sleeve | |
| 16 | 45A0019 | Gear | |
| 17 | 71A0058 | Carrier | |
| 18 | 33B0048 | Bearing | |
| 19 | 51C0171 | Diff assem | |
| 20 | 02B0410 | Bolt | |
| 21 | 06B0002 | Lock washer | |
| 22 | 55A1395 | Bearing cage | |
| 23 | 24A0539 | Lock plate | |
| 24 | 02B0030 | Bolt | |
| 25 | 06B0003 | Washer | |
| 26 | 45A0021 | Gear | |
| 27 | 01B0326 | Bolt | |
| 28 | 03B0340 | Nut | |
| 29 | 03B0289 | Nut | |
| 30 | 07B0091 | Snap ring | |
| 31 | 32B0010 | Bearing | |
| 32 | 33B0047 | Bearing |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
