Каталог запасных частей к технике: XGMA XG918. Meter Panel
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | SteeringWheel | Steering wheel | |
| 2 | ShifeLever | Shife lever | |
| 3 | TorqueConverterOilTemperatureGauge | Torque converter oil temperature gauge | |
| 4 | ElectricClock | Electric clock | |
| 5 | EngineWaterTemperatureGauge | Engine water temperature gauge | |
| 6 | ChargerIndicator | Charger indicator | |
| 7 | LeftTurnSignalIndicator | Left turn signal indicator | |
| 8 | EngineOilPressureAlarmIndicator | Engine oil pressure alarm indicator | |
| 9 | HighBeamIndicator | High beam indicator | |
| 10 | LowBeamIndicato | Low beam indicato | |
| 11 | Oil/WaterFilterJamAlarmIndicator | Oil/water filter jam alarm indicator | |
| 12 | RightTurnSignalIndicator | Right turn signal indicator | |
| 13 | AirPressuerIndicator | Air pressuer indicator | |
| 14 | BrakeSydtemAirPressureIndicator | Brake sydtem air pressure indicator | |
| 15 | VoltageMeter | Voltage meter | |
| 16 | TransmissionOilPressurwGauge | Transmission oil pressurw gauge | |
| 17 | TurnSignalLightController | Turn signal light controller | |
| 18 | Horn | Horn | |
| 19 | ElectricLockSwitch | Electric lock switch | |
| 20 | FuseBox | Fuse box |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
