Каталог запасных частей к технике: XGMA XG918. Electrical System
1
1
1
1
2
3
4
5
6
7
7
8
8
9
10
11
11
12
13
14
15
16
17
18
19
20
21
22
23
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 42B0112 | Front lamp | |
| 2 | 42B0117 | Front lamp assembled | |
| 3 | 47B0157 | Electricwipe assenbly | |
| 4 | 09C0236 | Line | |
| 5 | 42B0108 | Lamp | |
| 6 | 47B0155 | Fan | |
| 7 | 40B0114 | Sencor of temperature | |
| 8 | 42B0121 | Rear three signal lamp | |
| 9 | 09C0238 | Battery line | |
| 10 | 09C0209 | Battery line | |
| 11 | 47B0156 | Battery | |
| 12 | 44B0117 | Switch | |
| 13 | 09C0239 | Battery line | |
| 14 | 44B0116 | Air pressure on-off | |
| 15 | 09C0237 | Battery line | |
| 16 | ST30001 | Start up | |
| 17 | 09C0235 | Line | |
| 18 | 44B0214 | Arrester switch | |
| 19 | 47B0158 | Electric horn | |
| 20 | 42B0116 | Front lamp assembled | |
| 21 | 09C0234 | Chissis wires assembly | |
| 22 | 47B0172 | Reversing alarm | |
| 23 | 29C0071 | Assembly instrument |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
