Каталог запасных частей к технике: XGMA XG31651. Feet Break Assembly
1
2
3
4
5
6
7
7
8
9
10
11
12
12
12
13
14
15
16
16
17
17
18
18
18
19
19
19
20
20
21
22
23
24
25
26
27
28
29
30
31
32
33
33
33
34
35
36
37
38
39
40
41
42
43
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 25110021 | Right brake pipe | |
| 2 | 11020021 | Bolt | |
| 3 | 25040030 | Single-tube clip | |
| 4 | 20070029 | Adapter | |
| 5 | 20050034 | Adapter | |
| 6 | 25110020 | Left brake pipe | |
| 7 | 21030209 | Hydraulic Hose | |
| 8 | 16030029 | Washer | |
| 9 | 20080023 | Hollow bolt | |
| 10 | 20030003 | Adapter | |
| 11 | 16010024 | O-ring | |
| 12 | 20030001 | Joint | |
| 13 | 20040011 | Adapter | |
| 14 | 36060132 | Bolt | |
| 15 | 36010108 | Adapter Seat | |
| 16 | 20030097 | Adapter | |
| 17 | 21020137 | Hydraulic Hose | |
| 18 | 20050010 | Adapter | |
| 19 | 13010004 | Washer | |
| 20 | 12020005 | Nut | |
| 21 | 31060190 | Folding | |
| 22 | 10030018 | Bolt | |
| 23 | 16030034 | Washer | |
| 24 | 22210008 | Accumulator | |
| 25 | 21030042 | Hydraulic Hose | |
| 26 | 10030029 | Bolt | |
| 27 | 13010005 | Washer | |
| 28 | 22020023 | Gear Pumps | |
| 29 | 21030081 | Hydraulic Hose | |
| 30 | 21030367 | Hydraulic Hose | |
| 31 | 21030160 | Hydraulic Hose | |
| 32 | 21030066 | Hydraulic Hose | |
| 33 | 20040017 | Adapter | |
| 34 | 20030050 | Adapter | |
| 35 | 20030017 | Adapter | |
| 36 | 22060055 | AccumulatorValve | |
| 37 | 13010003 | Washer | |
| 38 | 11020070 | Bolt | |
| 39 | 21030198 | Hydraulic Hose | |
| 40 | 10030020 | Botl | |
| 41 | 22060054 | Braking Valve | |
| 42 | 24060022 | Oil pressure sensor | |
| 43 | 24060021 | Oil pressure sensor |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
