Каталог запасных частей к технике: XGMA XG31651. Carrier assy
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
18
19
19
20
20
21
22
23
24
25
26
27
28
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
42
43
43
44
44
45
45
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | PY180-H.1-4 | Nut | |
| 2 | PY180-H.1.2 | Universal joint fork assembly | |
| 3 | GB/T5782-2000 | Bolt | |
| 4 | GB/T93-87 | Washer | |
| 5 | GB/T5782-2000 | Bolt | |
| 6 | GB/T93-87 | Washer | |
| 7 | PY180-H.1-2 | Plate | |
| 8 | GB/T9877.1-88 | Seal | |
| 9 | GB/T9877.1-88 | Seal | |
| 10 | GB/T297-94 | Bearing | |
| 11 | PY180-H.1-5 | Bearing Cage | |
| 12 | PY180-H.1-1 | Adjustment mats | |
| 13 | PY180-H.1-6 | Spacer | |
| 14 | GB/T297-94 | Bearing | |
| 15 | PY180-H.1-3 | Driving bevel gear | |
| 16 | GB/T283-94 | Bearing | |
| 17 | GB/T5783-2000 | Bolt | |
| 18 | GB/T848-2002 | Washer | |
| 19 | PY180-H.1-9 | Lock plate | |
| 20 | PY180-H.1-8 | Nut | |
| 21 | JB/T1000-77 | Washer | |
| 22 | JB/T7941.2-95 | Oil mark | |
| 23 | GB/T5782-2000 | Bolt | |
| 24 | GB/T93-87 | Washer | |
| 25 | PY180-H.1-11 | Cover | |
| 26 | PY180-H.1-7 | pad | |
| 27 | PY180-H.1-7 | Main minus shell | |
| 28 | GB/T297-94 | Bearing | |
| 29 | PY180-H.1.1 | Differential assembly | |
| 30 | PY180-H.1-10 | Passive bevel gear | |
| 31 | PY180-H.1-13 | Slider | |
| 32 | PY180-H.1-16 | Cover | |
| 33 | GB/T879.1-2000 | pin | |
| 34 | GB/T6172.1-2000 | Nut | |
| 35 | GB/T79-2000 | Screw | |
| 36 | GB/T70.1-2000 | Screw | |
| 37 | GB/T5782-2000 | Bolt | |
| 38 | PY180-H.1.1-1 | Differential case | |
| 39 | PY180-H.1.1 | Differential assembly | |
| 40 | PY180-H.1.1-2 | Differential case | |
| 41 | 67035 | Spline bushing | |
| 42 | 66843 | Spring seat | |
| 43 | 66842 | Conical spring | |
| 44 | 66960 | Driven ring | |
| 45 | 66983 | Active ring |
