Каталог запасных частей к технике: XCMG ZL30G. Управление
1
1
2
2
2
2
2
3
3
3
3
4
4
5
6
7
8
8
9
9
10
10
11
11
12
13
14
15
16
17
18
19
20
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Diesel Engine Accessories | ||
| 2 | Diesel Engine Accessories | ||
| 3 | Diesel Engine Accessories | ||
| 4 | Diesel Engine Accessories | ||
| 5 | Z3G.7.3-4 | Link Block | |
| 6 | Diesel Engine Accessories | ||
| 7 | Diesel Engine Accessories | ||
| 8 | Diesel Engine Accessories | ||
| 9 | ZL40A.7.4-3 | Mat Seat | |
| 10 | ZL40.7.4-2 | Mat | |
| 11 | 180101 | Bearing GB279-88 | |
| 12 | Diesel Engine Accessories | ||
| 13 | Diesel Engine Accessories | ||
| 14 | Z3G.7.3.1 | Support | |
| 15 | Diesel Engine Accessories | ||
| 16 | Diesel Engine Accessories | ||
| 17 | Diesel Engine Accessories | ||
| 18 | Z3G.7.3-3 | Plate | |
| 19 | Z3G.7.3-2 | Shaft | |
| 20 | Z3G.7.3-1 | Link Plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
