Каталог запасных частей к технике: XCMG ZL30G. Планетарный редуктор
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 83030500 | Planetary Reductor Assembly | |
| 2 | 83020502 | Wheel Hub | |
| 3 | 2007124 | Bearing GB297-84 | |
| 4 | 2007126 | Bearing GB298-84 | |
| 5 | Diesel Engine Accessories | ||
| 6 | 79500823 | Snap Ring | |
| 7 | 77500938A | Internal Gear Assembly | |
| 8 | 76101041 | Taper | |
| 9 | 75501646 | Nut M85X2 | |
| 10 | Diesel Engine Accessories | ||
| 11 | 75501907C | O-Seal Ring | |
| 12 | 83020501 | Planet Carrier | |
| 13 | Diesel Engine Accessories | ||
| 14 | Diesel Engine Accessories | ||
| 15 | 75500842 | Plug M12X1.25 | |
| 16 | 79001544B | Cover | |
| 17 | 75000334A | Spacer | |
| 18 | 73520042 | Positioner | |
| 19 | Diesel Engine Accessories | ||
| 20 | Diesel Engine Accessories | ||
| 21 | Diesel Engine Accessories | ||
| 22 | Diesel Engine Accessories | ||
| 23 | 79001545A | Planet Shaft | |
| 24 | 79001547A | Planet Gear | |
| 25 | 79001524A | Sun Gear | |
| 26 | Diesel Engine Accessories | ||
| 27 | ZL40.2-9 | Wheel Pin M20X1.5 | |
| 28 | ZL40.2-10 | Wheel Nut M20 | |
| 29 | 80020001 | Axle Shaft | |
| 30 | 77000044 | Adjusting Pin | |
| 31 | 75600330 | Needle 6X30 | |
| 32 | 79500813A | Gasket |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
