Каталог запасных частей к технике: XCMG ZL30G. Электрооборудование
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | ZD2312 | Wiper | |
| 2 | YY242A3 | Engine Oil Pressure Meter | |
| 3 | Diesel Engine Accessories | ||
| 4 | SW242A | Water Temperature Meter | |
| 5 | ZDS-200 | Fan | |
| 6 | 8SQZ-30E | Signal Lamp | |
| 7 | YY242C | Air Pressure Meter | |
| 8 | CS130 | Head Lamp | |
| 9 | YW242B | t/M Oil Temperature Meter | |
| 10 | RY242A | Fuel Meter | |
| 11 | JK932-50G | Sw. | |
| 12 | FM221 | Warning Buzzer | |
| 13 | SG227B | Flasher | |
| 14 | BX508 | Fuse Box | |
| 15 | YG2221C | Engine Oil Pressure Meter | |
| 16 | WD134-1 | Rear Flood Lamp | |
| 17 | WG1371 | Temperature Meter | |
| 18 | Z3G.14.3 | Ground Wire | |
| 19 | Z3G.14.1 | Tail Lamp Wire Assembly | |
| 20 | Z3G.14.4 | Battery Link Wire | |
| 21 | YG2221C2 | Air Pressure Sensor | |
| 22 | RG1163M13 | Fuel Sensor | |
| 23 | FDJ | Alternator | |
| 24 | 6-QA-180 | Battery | |
| 25 | Z3G.14.6 | Sw.— Startor Wire | |
| 26 | Z3G.14.7 | Rear Chassis Wire Assembly | |
| 27 | MD | Startor | |
| 28 | DK2312A | Battery Relay | |
| 29 | JFT245A-28V | Regulator | |
| 30 | WG1371D | Temperature Sensor | |
| 31 | Z3G.14.2 | Right Box Wire Assembly | |
| 32 | JK114 | Sw. | |
| 33 | 08086-10000 | Wiper | |
| 34 | DY242A | Engine Oil Pressure Meter | |
| 35 | QJT5 | Working Lamp | |
| 36 | Z3G.14.9 | Water Temperature Meter | |
| 37 | Z3G.14-1 | Instrument Plate | |
| 38 | Z3G.14.8 | Signal Lamp | |
| 39 | DL50G(D)-24 | Horn | |
| 40 | Diesel Engine Accessories |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
