Каталог запасных частей к технике: XCMG XSM218 (XSM220). Рама задняя
1
2
3
4
5
5
5
5
5
6
7
8
9
9
9
10
10
10
11
12
13
14
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 39E047 | Oil Box | |
| 2 | A5-1783 | O-ring | |
| 3 | 34W004 | Cover | |
| 4 | A2-0079 | Filter | |
| 5 | C4-3200 | Washer | |
| 6 | C0-0140 | Bolt | |
| 7 | C3-3020 | Nut | |
| 8 | C0-2540 | Screw M8X25-ZND | |
| 9 | C0-0180 | Bolt | |
| 10 | C4-3820 | Washer 8 | |
| 11 | 39E002 | Plate | |
| 12 | 205281 | Rubber Absorber | |
| 13 | 205270 | Rubber Absorber Base | |
| 14 | 205175 | Washer | |
| 15 | C0-5260 | Bolt | |
| 16 | 39E031 | Cell Box | |
| 17 | 39E030 | Cover | |
| 18 | 39E004 | Washer | |
| 19 | C4-3320 | Washer | |
| 20 | C0-6895 | Bolt | |
| 21 | 39E003 | Bracket | |
| 22 | 39E165 | Left Breast Plate | |
| 23 | 204636 | Buffer | |
| 24 | C3-0060 | Nut M8-ZND | |
| 25 | 39E164 | Right Breast Plate | |
| 26 | Diesel Engine Accessories | ||
| 27 | Diesel Engine Accessories | ||
| 28 | Diesel Engine Accessories | ||
| 29 | Diesel Engine Accessories | ||
| 30 | Diesel Engine Accessories | ||
| 31 | 204330 | Plug | |
| 32 | 39E005 | Ventilative Plate | |
| 33 | 39E007 | Rear Frame | |
| 34 | 205180 | Washer | |
| 35 | C4-3360 | Washer | |
| 36 | C3-3121 | Nut | |
| 37 | C0-3600 | Bolt | |
| 38 | C4-3220 | Washer | |
| 39B010 | 39B010 | Rear Frame |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
