Каталог запасных частей к технике: XCMG XSM218, XSM220. Electric System
1
2
3
4
5
6
7
7
7
7
7
8
8
8
8
8
8
9
9
9
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
33
34
34
34
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 39Е401 | Control box | |
| 2 | D0-5708 | Petrol pump | |
| 3 | 404770 | Fixed screw | |
| 4 | 30021713 | Bat | |
| 5 | 30021715 | Rubber cover | |
| 6 | A7-7115 | Battery | |
| 7 | C0-2540 | Screw M8X25-ZND | |
| 8 | C4-3820 | Washer 8 | |
| 9 | C3-0060 | Nut M8-ZND | |
| 10 | C2-1660 | Screw M6X10-ZND | |
| 11 | C4-3180 | Washer 6 | |
| 12 | A7-5110 | Relay | |
| 13 | 39E402 | Relay bat | |
| 14 | Alternator | Alternator | |
| 15 | A7-4310 | Switch | |
| 16 | 39E406 | Cable | |
| 17 | 39E403 | Cable | |
| 18 | 39E404 | Cable | |
| 19 | 39E405 | Cable | |
| 20 | C2-1720 | Screw M5X16 | |
| 21 | C4-3150 | Washer 5 | |
| 22 | A7-5199 | Fuel gauge | |
| 23 | Starter | Starter | |
| 24 | А7-0003 | Stop switch | |
| 25 | А7-4307 | Near switch | |
| 26 | А7-5195 | Pressure sensor | |
| 27 | D0-7471 | Fuselage cable | |
| 28 | А7-0565 | Horn | |
| 29 | 201595 | Bracket | |
| 30 | 39Е410 | Cаble | |
| 31 | А7-0530 | Tie | |
| 32 | Fuse bох | Fuse bох | |
| 33 | Rear lamp | Rear lamp | |
| 34 | Steering lamp | Steering lamp | |
| 35 | Front lamp | Front lamp |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
