Каталог запасных частей к технике: XCMG XS143. 228401875 HYDRAULIC PROPULSION SYSTEM
1
2
3
4
5
8
9
11
12
14
15
16
17
18
20
21
22
23
24
25
28
29
30
32
33
34
37
38
39
40
41
42
43
44
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 803164766 | CONNECTOR | |
| 2 | 803103798 | Fitting | |
| 3 | 803105350 | BLIND FLANGE | |
| 4 | 803201542 | FLANGE | |
| 5 | 803104915 | Adapter | |
| 8 | 805301374 | WASHER 12 | |
| 9 | 803164538 | FILTER | |
| 11 | 803164539 | FILTER BOTTOM CASE | |
| 12 | 803164622 | CONNECTOR | |
| 14 | 228700446 | BOLT | |
| 15 | 805338259 | Washer | |
| 16 | 803164750 | CONNECTOR | |
| 17 | 803173684 | CONNECTOR | |
| 18 | 803107237 | CONNECTOR | |
| 20 | 805046624 | BOLT | |
| 21 | 226800344 | PIPE CLIP | |
| 22 | 228702481 | PPL PLATE | |
| 23 | 805338260 | Spring Washer | |
| 24 | 805046623 | BOLT M10x80 | |
| 25 | 805200080 | Locknut | |
| 28 | 803100741 | CONNECTOR | |
| 29 | 803164744 | CONNECTOR | |
| 30 | 803104947 | BLIND FLANGE | |
| 32 | 803164717 | FLANGE | |
| 33 | 803103340 | CONNECTOR | |
| 34 | 803164756 | Соединение | |
| 37 | 803105384 | Fitting | |
| 38 | 803004179 | MOTOR FOR DRIVING | |
| 39 | 805301377 | WASHER 16 | |
| 40 | 805006280 | Bolt | |
| 41 | 803192513 | O -RING 160x3.55 | |
| 42 | 803006989 | PROPULSION PUMP | |
| 43 | 805006413 | BOLTM12x35 | |
| 44 | 803164875 | CONNECTOR | |
| 45 | 803192131 | O-RING 125x3.55 | |
| 46 | 239902207 | RUBBER HOSE | |
| 47 | 239901910 | RUBBER HOSE | |
| 48 | 803195664 | RUBBER HOSE | |
| 49 | 860119054 | RUBBER HOSE | |
| 50 | 239901821 | RUBBER HOSE | |
| 51 | 803191608 | RUBBER HOSE | |
| 52 | 239901910 | RUBBER HOSE | |
| 53 | 803370326 | RUBBER HOSE | |
| 54 | 239900488 | RUBBER HOSE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
