Каталог запасных частей к технике: XCMG XE80. 803007194 Travel Motor
1
2
3
4
5
6
7
9
10
11
12
13
21
22
27
28
29
30
33
35
37
39
40
41
42
43
44
45
47
50
51
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
132
135
139
145
149
150
151
161
162
167
171
190
201
202
203
204
205
206
207
208
211
212
213
214
215
216
301
321
323
324
325
327
328
330
336
338
338
342
345
352
363
366
368
375
379
380
382
382
383
392
399
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 860119709 | Hub | |
| 2 | 860119710 | Spindle | |
| 3 | 860200432 | Carrier | |
| 4 | 860200433 | Sun gear (1) | |
| 5 | 860200434 | Planetary gear (1) | |
| 6 | 860200435 | Sun gear (2) | |
| 7 | 860200436 | Planetary gear (2) | |
| 9 | 860200437 | Thrust collar (1) | |
| 10 | 860200438 | Thrust washer (1) | |
| 11 | 860200439 | Thrust washer (2) | |
| 12 | 860200440 | Thrust washer (3) | |
| 13 | 860119711 | Cover | |
| 21 | 860200441 | Ball Bearing | |
| 22 | 860200442 | Ring nut | |
| 27 | 860200443 | Needle roller bearing | |
| 28 | 860200444 | Needle roller bearing | |
| 29 | 860200445 | Inner ring | |
| 30 | 860200446 | Inner ring | |
| 33 | 860200447 | Plug | |
| 35 | 803009548 | O-Ring | |
| 37 | 860200448 | O-Ring | |
| 39 | 860200449 | Plug | |
| 40 | 860200450 | Hex. Head bolt | |
| 41 | 860200451 | Steel ball | |
| 42 | 860200452 | Parallel-Pin | |
| 43 | 860200453 | O-Ring | |
| 44 | 860200454 | O-Ring | |
| 45 | 860200455 | Ring | |
| 47 | 860200456 | Hex. Socket set screw | |
| 50 | 860200457 | Retaining-Ring for | |
| 51 | 860200458 | Shaft | |
| 102 | 860200464 | Shaft | |
| 103 | 860200465 | Swash Plate | |
| 104 | 860200461 | Cylinder-Block | |
| 105 | 860200459 | Piston | |
| 106 | 860200460 | Shoe | |
| 107 | 860200466 | Retainer Plate | |
| 108 | 860200467 | Thrust Ball | |
| 109 | 860200468 | Time Plate | |
| 110 | 860200469 | Washer | |
| 111 | 860200470 | Washer | |
| 112 | 860200471 | Piston | |
| 113 | 860200472 | Spring | |
| 114 | 860200473 | Spring | |
| 115 | 860200474 | Friction Plate | |
| 116 | 860200475 | Mating Plate | |
| 132 | 860200476 | Oil Seal | |
| 135 | 860200477 | O-Ring | |
| 139 | 860200478 | O-Ring | |
| 145 | 860200479 | Snap ring for hole | |
| 149 | 860200480 | Ball Bearing | |
| 150 | 860200481 | Ball Bearing | |
| 151 | 860200482 | Roller | |
| 161 | 860200462 | Piston | |
| 162 | 860200463 | Shoe | |
| 167 | 860200483 | Pivot | |
| 171 | 860200484 | Parallel-Pin | |
| 190 | 860200485 | Spring | |
| 201 | 860200486 | Valve seat | |
| 202 | 860200487 | Valve | |
| 203 | 860200488 | Sleeve | |
| 204 | 860200489 | Collar | |
| 205 | 860200490 | Plug | |
| 206 | 860200491 | Spring | |
| 207 | 860200492 | O-Ring | |
| 208 | 860200493 | Back-up ring | |
| 211 | 860200494 | O-Ring | |
| 212 | 860200495 | O-Ring | |
| 213 | 860200496 | Shim | |
| 214 | 860200497 | Piston | |
| 215 | 860200498 | O-Ring | |
| 216 | 860200499 | Back-up ring | |
| 301 | 860200500 | Rear flange | |
| 321 | 860200509 | Plug | |
| 323 | 860200501 | Spool | |
| 324 | 860200510 | Plug | |
| 325 | 860200511 | Spring retainer | |
| 327 | 860200512 | Valve | |
| 328 | 860200513 | Spring | |
| 330 | 860200514 | Spring | |
| 336 | 860200515 | O ring | |
| 338 | 860200516 | O ring | |
| 342 | 860200521 | Parallel pin | |
| 345 | 860200522 | Hex. Socket bolt | |
| 352 | 860200502 | Hex. Socket plug | |
| 363 | 860200517 | Spool | |
| 366 | 860200518 | Spring | |
| 368 | 860200503 | Steel ball | |
| 375 | 860200504 | Hex. Socket plug | |
| 379 | 860200505 | Filter | |
| 380 | 860200506 | Orifice | |
| 382 | 860200519 | Plug | |
| 383 | 860200507 | Plug | |
| 392 | 860200520 | O ring | |
| 399 | 860200508 | Name plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
