Каталог запасных частей к технике: XCMG XE80. 803007194 Travel Motor
1
2
3
4
5
6
7
9
10
11
12
13
21
21
22
27
28
29
30
33
35
37
39
40
41
42
43
44
45
47
50
51
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 860119709 | Hub | |
| 2 | 860119710 | Spindle | |
| 3 | 860200432 | Carrier | |
| 4 | 860200433 | Sun gear (1) | |
| 5 | 860200434 | Planetary gear (1) | |
| 6 | 860200435 | Sun gear (2) | |
| 7 | 860200436 | Planetary gear (2) | |
| 9 | 860200437 | Thrust collar (1) | |
| 10 | 860200438 | Thrust washer (1) | |
| 11 | 860200439 | Thrust washer (2) | |
| 12 | 860200440 | Thrust washer (3) | |
| 13 | 860119711 | Cover | |
| 21 | 860200441 | Ball Bearing | |
| 22 | 860200442 | Ring nut | |
| 27 | 860200443 | Needle roller bearing | |
| 28 | 860200444 | Needle roller bearing | |
| 29 | 860200445 | Inner ring | |
| 30 | 860200446 | Inner ring | |
| 33 | 860200447 | Plug | |
| 35 | 803009548 | O-Ring | |
| 37 | 860200448 | O-Ring | |
| 39 | 860200449 | Plug | |
| 40 | 860200450 | Hex. Head bolt | |
| 41 | 860200451 | Steel ball | |
| 42 | 860200452 | Parallel-Pin | |
| 43 | 860200453 | O-Ring | |
| 44 | 860200454 | O-Ring | |
| 45 | 860200455 | Ring | |
| 47 | 860200456 | Hex. Socket set screw | |
| 50 | 860200457 | Retaining-Ring for | |
| 51 | 860200458 | Shaft | |
| 102 | 860200464 | Shaft | |
| 103 | 860200465 | Swash Plate | |
| 104 | 860200461 | Cylinder-Block | |
| 105 | 860200459 | Piston | |
| 106 | 860200460 | Shoe | |
| 107 | 860200466 | Retainer Plate | |
| 108 | 860200467 | Thrust Ball | |
| 109 | 860200468 | Time Plate | |
| 110 | 860200469 | Washer | |
| 111 | 860200470 | Washer | |
| 112 | 860200471 | Piston | |
| 113 | 860200472 | Spring | |
| 114 | 860200473 | Spring | |
| 115 | 860200474 | Friction Plate | |
| 116 | 860200475 | Mating Plate | |
| 132 | 860200476 | Oil Seal | |
| 135 | 860200477 | O-Ring | |
| 139 | 860200478 | O-Ring | |
| 145 | 860200479 | Snap ring for hole | |
| 149 | 860200480 | Ball Bearing | |
| 150 | 860200481 | Ball Bearing | |
| 151 | 860200482 | Roller | |
| 161 | 860200462 | Piston | |
| 162 | 860200463 | Shoe | |
| 167 | 860200483 | Pivot | |
| 171 | 860200484 | Parallel-Pin | |
| 190 | 860200485 | Spring | |
| 201 | 860200486 | Valve seat | |
| 202 | 860200487 | Valve | |
| 203 | 860200488 | Sleeve | |
| 204 | 860200489 | Collar | |
| 205 | 860200490 | Plug | |
| 206 | 860200491 | Spring | |
| 207 | 860200492 | O-Ring | |
| 208 | 860200493 | Back-up ring | |
| 211 | 860200494 | O-Ring | |
| 212 | 860200495 | O-Ring | |
| 213 | 860200496 | Shim | |
| 214 | 860200497 | Piston | |
| 215 | 860200498 | O-Ring | |
| 216 | 860200499 | Back-up ring | |
| 301 | 860200500 | Rear flange | |
| 321 | 860200509 | Plug | |
| 323 | 860200501 | Spool | |
| 324 | 860200510 | Plug | |
| 325 | 860200511 | Spring retainer | |
| 327 | 860200512 | Valve | |
| 328 | 860200513 | Spring | |
| 330 | 860200514 | Spring | |
| 336 | 860200515 | O ring | |
| 338 | 860200516 | O ring | |
| 342 | 860200521 | Parallel pin | |
| 345 | 860200522 | Hex. Socket bolt | |
| 352 | 860200502 | Hex. Socket plug | |
| 363 | 860200517 | Spool | |
| 366 | 860200518 | Spring | |
| 368 | 860200503 | Steel ball | |
| 375 | 860200504 | Hex. Socket plug | |
| 379 | 860200505 | Filter | |
| 380 | 860200506 | Orifice | |
| 382 | 860200519 | Plug | |
| 383 | 860200507 | Plug | |
| 392 | 860200520 | O ring | |
| 399 | 860200508 | Name plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
