Каталог запасных частей к технике: XCMG XE80. 803007180 Main Pump

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Позиция на иллюстрации Заводской номер детали Название детали
1 860200217 Shaft
2 803181792 Oil Seal
3 860200218 Shim
4 860200219 Housing
5 860200220 Taperd Roller Brg
6 860200221 Screw
7 860200222 Cradle
8 860200223 Cam
9 803009499 Return Plate
10 803009500 Piston Assembly
11 803009501 Cylinder
12 803009502 Port Plate Cw
13 860200224 Ring
14 860200225 Bush
15 860200226 Spring
16 860200227 Cradle L
17 860200228 Retainer Sph
18 860200229 O-Ring
19 860200230 Pin
20 860200231 Needle Brg
21 860200232 O-Ring
22 860200233 Adjust Screw
23 860200234 Hex.Nut
24 860200523 Nut
25 860200235 Cap SP
26 860200236 O-Ring
27 860200237 O-Ring
28 860200238 Sleeve
29 860200239 O-Ring
30 860200240 Spring
31 860200241 Spring
32 860200242 Spring Guide
33 860200243 Rod Pw
34 860200244 Sleeve
35 860200245 Pin
36 860200246 Servo Case
37 860200247 Rod
38 860200248 Piston B
39 860200249 Piston U
40 860200250 Cap
41 860200251 O-Ring
42 860200252 Power Piston Las
43 860200253 O-Ring
44 860200254 Cap Sr
45 860200255 Spring
46 860200256 O-Ring
47 860200257 Back Up Ring
48 860200258 Stopper
49 860200259 Cap
50 860200260 Hex.Nut
51 860200261 Set Screw
52 803181793 Seal Retainer
53 860200262 Hex.Socket Bolt
54 860200263 O-Ring
55 860200264 Guide
56 860200265 Rod Re
57 860200266 Spring
58 860200267 Piston Re
59 860200268 Cover
60 860200269 Spring
61 860200270 Bush
62 860200271 Spring
63 860200272 Plug
64 860200273 O-Ring
65 860200274 Cap Re
66 860200275 Coupling
67 860200276 Gear Pump
68 860200277 Snap Ring
69 860200278 Plug
70 860200279 Hex.Socket Bolt
71 860200280 Link
72 860200281 Pin
73 860200282 O-Ring
74 860200283 Hex.Socket Bolt
75 860200284 Hex. Bolt
76 860200285 Washer
77 860200286 Hex.Socket Bolt
78 860200287 Servocase As
79 860200288 Cap As
80 860200289 Elbow
81 860200290 Hose
82 860200291 Connector
83 860200292 Relief Block As
84 860200293 O-Ring
85 860200294 Cap
86 860200295 Hex.Socket Bolt
87 860200296 Filter
88 860200297 Manifold
89 860200298 Rerief As
90 860200299 O-Ring
91 860200300 Hose As
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
