QY16K.70 Center Revolving Body
QY16K.70 II Center Revolving Body
QY50K.72A Outrigger Operation System
1
2
3
3
4
4
5
6
7
8
9
10
11
11
12
12
13
14
15
16
Позиция на иллюстрации
Заводской номер детали
Название детали
1
QY16K.70II.2
Electric brush
2
QY16K.70-6A
Pressing plate
3
10440001
Washer 8
4
10410011
Bolt M8x20
5
20130079
Revolving sealing
6
QY16K.70.4B
Sleeve pipe
7
20130071
O seal ring
8
10430005
Nut M12
9
QY16K.70H-1
Fix body
10
QY16K.70.1A
Support
11
10410040
Bolt M12x40
12
10440010
Washer 12
13
10430005
Nut M12
14
QY16K.70.5
Transmission fork
15
10410038
Bolt M10x30
16
10440006
Washer 10
17
10130009
Sсrеw plug М42х2
18
10130801
Screw plug
19
10130095
Sсrеw plug М10х1
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
