Каталог запасных частей к технике: WIRTGEN W600DC. LIGHTING / WARNING DEVICE
1
1
1
1
1
2
2
2
3
3
4
5
5
6
7
7
8
9
10
11
11
12
13
13
14
14
15
15
15
15
16
16
17
17
17
18
18
18
18
18
18
18
19
20
21
22
22
23
23
24
24
24
25
25
25
26
26
26
27
27
28
29
30
30
31
32
32
33
33
34
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 10906 | WORKING LIGHT | |
| 2 | 9778 | BULB FOR WORK LIGHT | |
| 3 | 68407 | PATROL LIGHT YELLOW | |
| 4 | 16224 | BULB FOR PATROL LIGHT | |
| 5 | 103085 | HOLDER | |
| 6 | 6515 | HOLDER | |
| 7 | 28825 | PROTECTING CAP | |
| 8 | 63882 | LAMPHOLDER WITH SOCKET | |
| 9 | 65068 | SERRATED LOCK WASHER | |
| 10 | 9879 | SCREW | |
| 11 | 4262 | SCREW | |
| 12 | 5192 | HEXAGON NUT | |
| 13 | 9230 | HOLDER | |
| 14 | 4219 | SCREW | |
| 15 | 5274 | WASHER | |
| 16 | 5269 | HEXAGON NUT | |
| 17 | 4177 | SCREW | |
| 18 | 5206 | WASHER | |
| 19 | 20136 | PLUG SOCKET | |
| 20 | 27406 | SECURITY CLIP | |
| 21 | 20135 | PLUG | |
| 22 | 7983 | PLUG SOCKET | |
| 23 | 8014 | PLUG | |
| 24 | 19031 | SCREW | |
| 25 | 31632 | WASHER | |
| 26 | 4178 | SCREW | |
| 27 | 36799 | HOLDER | |
| 28 | 8012 | PLUG | |
| 29 | 7982 | PLUG SOCKET | |
| 30 | 4179 | SCREW | |
| 31 | 10251 | SPIRAL CABLE | |
| 32 | 8015 | HORN | |
| 33 | 52599 | FREE WHEEL DIODE CPL. | |
| 34 | 5208 | WASHER |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
