Каталог запасных частей к технике: WIRTGEN W600DC. LIGHTING / WARNING DEVICE
1
2
3
4
5
6
7
7
8
8
9
9
10
10
11
12
13
14
15
16
16
16
16
17
17
17
17
18
18
18
19
19
20
21
21
22
23
24
25
26
26
26
26
26
28
29
29
30
30
31
31
31
32
32
32
32
32
32
33
33
33
34
35
36
36
36
36
36
36
36
37
38
39
39
40
41
42
42
43
44
44
45
45
46
47
48
49
49
50
51
52
53
54
54
55
55
56
57
58
59
60
60
61
61
62
62
63
64
65
66
67
68
69
70
71
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 58478 | LAMP SUPPORT | |
| 2 | 57589 | SOCKET PIPE | |
| 3 | 15814 | SCREW | |
| 4 | 68407 | PATROL LIGHT YELLOW | |
| 5 | 6972 | PLASTIC HOUSING | |
| 6 | 11194 | REAR LIGHT | |
| 7 | 10183 | BULB | |
| 8 | 10180 | BULB | |
| 9 | 8210 | SCREW | |
| 10 | 9379 | HEXAGON NUT | |
| 11 | 12846 | SCHNORR TOOTH LOCK WASHER | |
| 12 | 31632 | WASHER | |
| 13 | 39917 | POSITION LIGHT | |
| 14 | 8214 | SCREW | |
| 15 | 35433 | REAR REFLECTOR | |
| 16 | 8216 | SCREW | |
| 17 | 5801 | WASHER | |
| 18 | 15502 | REAR REFLECTOR | |
| 19 | 8014 | PLUG | |
| 20 | 61966 | STICKER | |
| 21 | 99425 | WARNING SIGN | |
| 22 | 125766 | LAMP SUPPORT | |
| 23 | 9560 | PLUG SOCKET | |
| 24 | 28825 | PROTECTING CAP | |
| 25 | 16224 | BULB FOR PATROL LIGHT | |
| 26 | 9798 | HEXAGONAL NUT | |
| 27 | 111295 | HOLDER | |
| 28 | 5942 | SCREW | |
| 29 | 5799 | WASHER | |
| 30 | 121819 | HINGE PLATE | |
| 31 | 5940 | SCREW | |
| 32 | 5800 | WASHER | |
| 33 | 5810 | HEXAGON NUT | |
| 34 | 121730 | COVER | |
| 35 | 4178 | SCREW | |
| 36 | 5206 | WASHER | |
| 37 | 6683 | CAP NUT | |
| 38 | 17439 | SILENTBLOC | |
| 39 | 5209 | HEXAGON NUT | |
| 40 | 5211 | WASHER | |
| 41 | 121844 | DISTANCE PLATE | |
| 42 | 4180 | SCREW | |
| 43 | 121842 | HOLDER | |
| 44 | 36126 | WASHER | |
| 45 | 4834 | THUMB NUT | |
| 46 | 121875 | DISTANCE PLATE | |
| 47 | 121872 | HOLDER | |
| 48 | 4183 | SCREW | |
| 49 | 7983 | PLUG SOCKET | |
| 50 | 8219 | SCREW | |
| 51 | 5804 | WASHER | |
| 52 | 8085 | BULB | |
| 53 | 8218 | SCREW | |
| 54 | 4122 | PIPE CLIP | |
| 55 | 5944 | SCREW | |
| 56 | 122211 | PLATE | |
| 57 | 4179 | SCREW | |
| 58 | 5208 | WASHER | |
| 59 | 40018 | HOLDER | |
| 60 | 4218 | SCREW | |
| 61 | 5271 | WASHER | |
| 62 | 5274 | WASHER | |
| 63 | 40019 | HOLDER | |
| 64 | 35434 | WORK LIGHT | |
| 65 | 35436 | FLASHLIGHT | |
| 66 | 47453 | BULB | |
| 67 | 8215 | SCREW | |
| 68 | 46115 | HEXAGON NUT | |
| 69 | 162833 | ANGLE | |
| 70 | 8647 | PADLOCK | |
| 71 | 111295 | HOLDER |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
