Каталог запасных частей к технике: WIRTGEN W200. TOOLS

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
16
20
21
22
23
30
31
32
40
40
41
42
43
44
45
50
51
52
53
54
55
60
61
62
63
64
65
66
70
71
75
76
77
78
79
85
86
87
88
90
91
99
Позиция на иллюстрации Заводской номер детали Название детали
1 72612 SET OF TOOLS
2 72440 TOOLBOX WITHOUT TOOLS
3 5379 OPEN-END SPANNER 6-7
4 5380 OPEN-END SPANNER 8-9
5 5381 OPEN-END SPANNER 10-11
6 5382 OPEN-END SPANNER 12-13
7 5383 OPEN-END SPANNER 14-15
8 5470 OPEN-END SPANNER 17-19
9 5387 OPEN-END SPANNER 20-22
10 5390 OPEN-END SPANNER 24-27
11 5391 OPEN-END SPANNER 30-32
12 5392 OPEN-END SPANNER 32-36
13 5393 OPEN-END SPANNER 41-46
14 5394 OPEN-END SPANNER 50
15 5395 OPEN-END SPANNER 55
16 5396 OPEN-END SPANNER 60
20 5444 POINT SET SPANNER SET 2-14
21 5997 FLAT CHISEL 20x200
22 5441 HAMMER WITH HANDLE
23 5442 COPPER HAMMER
30 5361 SCREW DRIVER
31 5363 SCREW DRIVER
32 18934 SCREW DRIVER 2,5X 75
40 10634 EAR PROTECTION
41 5465 STEEL BRUSH
42 11078 PIPE WRENCH
43 6001 SLIP-JOINT GRIPS
44 5447 ASSEMBLY PLIERS F LOCKING RING
45 6002 SIDE CUTTER
50 11054 GREASE GUN
51 11089 HOSE FOR GREASE GUN
52 11136 SLIDING COUPLING
53 2468032 FOLDING RULE
54 84642 ALLAN KEY 6
55 84643 ALLAN KEY 17
60 10541 HEXAGON INSET SOCKET
61 10579 HEXAGON INSET SOCKET
62 12616 HEXAGON INSET SOCKET
63 11151 HEXAGON SOCKET 14MM FOR HT3
64 11886 HEXAGON SOCKET 17MM FOR HT2
65 11887 HEXAGON INSET SOCKET
66 176867 HEXAGON INSET SOCKET
70 33298 HEXAGON INSET SOCKET
71 42665 HEXAGON INSET SOCKET
75 159205 HEXAGONAL SOCKET
76 10529 HEX SOCKET 24MM-3/4"
77 11269 HEX SOCKET 30MM-3/4"
78 78334 HEX SOCKET 32MM-3/4"
79 20034 HEX SOCKET 36MM-3/4"
85 5438 RATCHET
86 10747 EXTENSION 3/4"
87 10578 RATCHET EXTENSION
88 40984 SQUARE REDUCER
90 2262486 PIN SPANNER
91 2151487 TORX SOCKET
99 8647 PADLOCK
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
