Каталог запасных частей к технике: WIRTGEN W200. STORAGE COMPARTMENTS
1
2
2
3
3
4
5
5
6
7
7
8
9
10
11
12
13
14
14
15
15
15
15
16
16
17
18
19
20
21
21
22
22
23
23
23
24
24
25
26
27
28
29
29
30
30
30
30
31
32
33
34
35
36
36
37
37
38
38
39
40
41
42
43
44
45
46
47
47
48
49
50
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 2243322 | STORAGE COMPARTMENT | |
| 2 | 4217 | SCREW | |
| 3 | 51958 | WASHER | |
| 4 | 2218711 | HOLDER | |
| 5 | 4219 | SCREW | |
| 6 | 5274 | WASHER | |
| 7 | 2112628 | NUT | |
| 8 | 4220 | SCREW | |
| 9 | 51958 | WASHER | |
| 10 | 51958 | WASHER | |
| 11 | 5269 | HEXAGON NUT | |
| 12 | 51958 | WASHER | |
| 13 | 2243077 | COVER | |
| 14 | 4222 | SCREW | |
| 15 | 51958 | WASHER | |
| 16 | 5269 | HEXAGON NUT | |
| 17 | 176485 | WASHER | |
| 18 | 7698 | SCREW | |
| 19 | 5206 | WASHER | |
| 20 | 12247 | HEXAGON NUT | |
| 21 | 143068 | FIXING LEVER | |
| 22 | 5940 | SCREW | |
| 23 | 68267 | WASHER | |
| 24 | 5810 | HEXAGON NUT | |
| 25 | 2243127 | DOOR | |
| 26 | 2053079 | SASH LOCK | |
| 27 | 106182 | TONGUE | |
| 28 | 187008 | HINGE | |
| 29 | 4178 | SCREW | |
| 30 | 5206 | WASHER | |
| 31 | 12247 | HEXAGON NUT | |
| 32 | 6218 | CAP NUT | |
| 33 | 2199864 | STORAGE COMPARTMENT | |
| 34 | 2113436 | LID | |
| 35 | 110626 | HINGE | |
| 36 | 160477 | SCREW | |
| 37 | 5206 | WASHER | |
| 38 | 12247 | HEXAGON NUT | |
| 39 | 2053079 | SASH LOCK | |
| 40 | 106182 | TONGUE | |
| 41 | 133137 | SILENTBLOC | |
| 42 | 131621 | SCREW | |
| 43 | 5801 | WASHER | |
| 44 | 32783 | HEXAGON NUT | |
| 45 | 4219 | SCREW | |
| 46 | 51958 | WASHER | |
| 47 | 2202149 | ANTISLIP FLOOR COVERING | |
| 48 | 131753 | SCREW | |
| 49 | 5206 | WASHER | |
| 50 | 6683 | CAP NUT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
